Swinging Patio Door Parts

Part Number 820R  Hoppe Multipoint Automatic Roller Top Extension HLS9000 for HURD DOORS ONLY CUSOTMER PLEASE READ BEFORE YOU ORDER: See chart for dimensions to compare with your multipoint BEFORE you place your order. If measurements do not match for your multipoint please email us for the worksheet you will need to fill out for a quote. Single point gearbox is not interchangeable with multipoint gearbox. The cover may look the same but internal components are different.  Material: Stainless Steel (sliver). Brass color no longer manufactured - only comes in stainless steel for both the gear box and the extension. See features and benefits picture.  Style: Roller Top Extension ONLY Size we stock: (see chart for full details and measurements):  6-8 = Top Extension Length 1019mm / 40.11in Retro = Top Extension Length 1031mm / 40.59in 6-10 = Top Extension Length 1078mm / 42.44in 8-0 = Top Extension Length 1407mm / 55.39in Comes with: Top extension ONLY (Bottom Extension with Gearbox SOLD separately see part number 810R for bottom extension with gear box)  The Hoppe #810R/820R Roller style is the direct replacement for old FUHR Roller Multi point that was on Hurd and other door manufactures – no modification is needed when changing to the Hoppe #810 - you need to order both top extension 820 and lower extension with great box 810 to use as a replacement with old FUHR. The only difference is some of the FUHR multi point had an automatic fire to engage the multi point, the Hoppe does not. So with the Hoppe to engage the multi point you close the door then lift up on the door handle then throw the dead bolt to lock. Associated Parts Sold Separately: 810R - Hoppe Multipoint Automatic Roller Lower Gearbox with Extension HLS9000 813 -  Hoppe 3Pt Convert Auto Release Striker  833 -  Hoppe 3Pt Convertible Under plate  834 - Hoppe 3Pt Striker For Rollers 819 - Hoppe Multipoint Latch Plate  S4019 - Hoppe LATCH AND DEADBOLT STRIKE WITH CURVED LIP S1400AC - Active with Cylinder Munchen Series M112PI/216N Handle Set S4300AC - Active with Cylinder Hoppe Munchen Series M112PI/3965N Handle Set S4200AC - Active with Cylinder Hoppe Munchen Series M112PI/374N Handle Set S4100AC - Active with Cylinder Hoppe Munchen Series M112PI/216N Other Hoppe Multipoint and Single Point We Stock: 810T - Hoppe Multipoint Automatic Tongue Lower Extension HLS9000 820T - Hoppe Multipoint Automatic Tongue TOP Extension HLS9000 825 - Hoppe Single point Gear Box For Hoppe Multipoint We Do Not Stock Please Email us for worksheet and quote  Install Instructions (also see instructions in pictures): Remove set screws on handle levers and remove remove three mounting screws on faceplate estuation  On side of door remove screw that lines up with the lock cylinder. Remove the handle set Remove all screws down the side of the door that holds on the multipoint system (keep all screws you will reuse them) Install new multipoint with screws Test for Operation  Reinstall handle set Test for proper operation 810R/820R Known to have been used on: For Classic Hurd Doors Manufactured from 2005 and Prior. Fuhr Multi point used on Classic Hurd doors are no longer manufactured - Hoppe Multi point is the direct replacement. Number Known To Have Been On Older Gear Box (Hoppe Roller Style Brass Color): 1334291 - this is a component number.

Read more less

Part Number 881 GU Multi Point In Swinging Door Strike Colors:  Stainless Steel and Oil Rubbed Bronze  Discontinued colors: All other colors below have been discontinued and no longer available. Any stock we still have is AS IS no return. Antique Brass Bright Brass Polished Chrome White Screws Not Included: Factory Recommends using 7 x 5/8 PH FH Screw Known to be used on: GU, Hurd and Sierra pacific WI in-swinging wood/clad doors.

Read more less

Special order items estimated lead time 2-6 weeks. No returns or order cancellations  Part Number: S4114 GU Ferco 45MM Capri Lever  Swinging Door Handles Trim Sets - Handle Above Cylinder Handle trim Set only Capri Lever Handle Above Cylinder Style (as pictured for 1 door panel)  - multi or single point mortise boxes  sold separately  45 MM Trim Plate Capri Lever Handle Above Cylinder  Solid Brass or Zamac Trim Sets Stainless steel set screw on levers to secure spindle US cylinder with standard Schlege "c" keyway (active only) 90 degree locking with thrumb turn (for active and semi active) Unassembled kit for 1 3/4" and 2 1/4" thick doors Self- Centering Spindle Use with Mortise lock, SECURY S2, SH2 and SECURY Automatic Door Gears  Patented handle clipping system.  Screw Hole Spacing: 7-3/4 inch Zamac Available in: Dark Bronze, Black and White Solid Brass Available In: Satin Chrome, Polished Brass, Antique Brass, Oil Rubbed Bronze, Satin Nickel, Dark Bronze, Pewter and Black Style: Active, Semi Active and Dummy Scroll thru pictures  for dimentions and manufacture installation and trouble shooting instructions.

Read more less

Part Number: S4015 - Truths Sentry Adjustable Hinges - Guide Hinges If not in stock but a preorder item then it’s a Special order Item No Returns  Screws Not Included Engineered for maximum strength and security, Sentry Hinges exceed ANSI grade 3 requirements fordoors weighing up to 220 lbs. Sentry Hinges exceed ANSI grade 1 impact specifications. Sentry Hinges aremade of extruded brass and extruded aluminum that provides superior strength and corrosion resistance.Sentry Hinges provided with non-removable pins for maximum security. Robust, Reliable and Attractive Industry standard 4" x 4" with 5/8" radius corner Both Guide (Part # S4015) and Set (Part # S4016) Hinges take a 5/32" hex wrench Guide Hinge (Part # S4015) has a 11/64" adjustment and Set Hinge (Part # S4016) has a 1/4" adjustment Extruded brass hinges are provided in decorative finishes including PVD Extruded aluminum hinges are available in powder coated painted finishes Composite bushings provide noise-free operation Set and Guide Hinge Placement: 3 Hinges Per Door Panel: Starting at top of door Top of door Guide Set Guide   4 Hinges Per Door Panel: Anytime you need 4 hinges you would just add another guide hinge Starting at top of door Top of door Guide Guide  Set Guide The Set hinge no matter what is always the 2nd from the bottom Pro Tip: Remove weight from the hinges by lifting up on the door before you adjust.

Read more less

Part Number: S4016 - Truths Sentry Adjustable Hinges - Set Hinges If not in stock but a pre order item then it’s a Special order Item No Returns  Screws Not Included Engineered for maximum strength and security, Sentry Hinges exceed ANSI grade 3 requirements fordoors weighing up to 220 lbs. Sentry Hinges exceed ANSI grade 1 impact specifications. Sentry Hinges aremade of extruded brass and extruded aluminum that provides superior strength and corrosion resistance.Sentry Hinges provided with non-removable pins for maximum security. Robust, Reliable and Attractive Industry standard 4" x 4" with 5/8" radius corner Both Guide (Part # S4015) and Set (Part # S4016) Hinges take a 5/32" hex wrench Guide Hinge (Part # S4015) has a 11/64" adjustment and Set Hinge (Part # S4016) has a 1/4" adjustment Extruded brass hinges are provided in decorative finishes including PVD Extruded aluminum hinges are available in powder coated painted finishes Composite bushings provide noise-free operation Set and Guide Hinge Placement:     3 Hinges Per Door Panel:     Starting at top of door Top of door     Guide     Set     Guide     4 Hinges Per Door Panel:     Anytime you need 4 hinges you would just add another guide hinge     Starting at top of door Top of door     Guide     Guide      Set     Guide     The Set hinge no matter what is always the 2nd from the bottom     Pro Tip: Remove weight from the hinges by lifting up on the door before you adjust.

Read more less

Part Number:  S4012 – Guide Hinge Hoppe Adjustable Hinge - Guide Hinge - Non Removable Pin Style. S4012 is Horizontal Adjustment Only (Watch video and read instructions in picture's) No Screws Included, sold individually  GUIDE HINGES ARE NOT HANDED. Will work on both LH and RH Doors by how you mount the hinge If not in stock - Pre Order - Special order item - no return 3-8 week lead time  Made out of Brass or Aluminum. Multiple finishes to choose from.  Designed for a Greater Advantage • To Adjust vertically (Use Set Hinge Part # S4011) and  for horizontally (Use Guide Hinge Part # S4012) by 1/8" for a perfect swing. See Installation Set and Guide Hinge Placement • Brass hinges feature finial caps as shown • Aluminum hinges feature flush caps. • Large 3/16" hex head screws make adjustments effortless. Remove the finial in the set hinge to access the hex screw. • Single pass routing for quick and easy installation. • All Set and Guide Hinges are equipped with non-removable pins for security, making HOPPE Adjustable Hinges the ideal solution for both inswing and outswing doors. • Especially designed for larger doors, with a panel weight capacity of up to 330 lbs. Tested to a Higher Standard • Brass hinges are tested beyond an impressive 2.5 million cycles, in accordance with ANSI A156.1 Grade 1 – Commercial test procedures. • Backed by HOPPE's Limited Lifetime Mechanical Warranty. Finished with Superior Quality HOPPE's Brass and Aluminum Hinges are outstanding corrosion resistant materials HOPPE uses their Resista® Limited Lifetime Finish Warranty on four of their select premium finishes. The Aluminum Hinges have a high quality powder coating finish. Installation Set and Guide Hinge Placement: 3 Hinges Per Door Panel Up to 165 lbs: Starting at top of door Top of door Guide (Use Part# S4012) Set (Use Part# S4011) Guide (Use Part# S4012) 4 Hinges Per Door Panel Up To 165 lbs: Starting at top of door Top of door Guide (Use Part # S4012)  Guide (Use Part # S4012)  Set (Use Part# S4011) Guide (Use Part # S4012) 4 Hinge Per Door Panel 165-330 lbs Starting at top of door Top of door Guide (Use Part # S4012)   Set (Use Part# S4011)  Set (Use Part# S4011) Guide (Use Part # S4012) 5 Hinges Per Door Panel Up To 165-330 lbs: Starting at top of door Top of door Guide (Use Part # S4012)  Guide (Use Part # S4012) Set (Use Part# S4011)  Set (Use Part# S4011) Guide (Use Part # S4012)  The Set hinge no matter what is always the 2nd from the bottom Pro Tip: Remove weight from the hinges by lifting up on the door before you adjust.  Known to have been used on Sierra Pacific Doors and Ashworth

Read more less

As is - New Condition old stock (may have minor scuffs, etc.) - No returns all sales final. Once our stock is gone this item will no longer be available. 840-008 - Amesbury Truth GU Handle - Set Screw and Shaft Type - Swinging Patio Door Hurd. Replacement handle only. All other replacement parts sold separately.  Discontinued Product. What we have in stock is all that is available. No returns, all sales final. Some may have minor scratches.

Read more less

Part Number 837 Adjustable Oak Threshold For Hurd Clad & Wood In swing Patio Doors. Built 1988 thru 1994Thresholds will not fit tight end to end as there needs to be a small gap on both sides for water weep purposes. - Old weep system threshold.Size:2-6 Size = Threshold is 27 7/8 Inch Long2-8 Size = Threshold is 29 7/8 Inch Long3-0 Size = Threshold is 27 7/8 Inch Long INSTRUCTIONS FOR P#837 To remove old threshold: Use a #3 Philips bit on your drill - to unscrew the screws on the top of the old oak threshold all the way. Once screws are completely removed the old threshold will pull up. There are T nuts in a T track underneath the threshold that the screws screw into. You can reuse the old T nuts or replace the T nuts in the T track with the new T nuts provided with the new threshold To replace the T nuts – you will remove the old T nuts by sliding them out of the track – there should be a space at one of the ends of the track for you to do this. Take new T nuts and slide them into the track through the same space at one of the ends of the T track. Replace with new threshold by aligning the T nuts to the screws in the threshold. Screw in all screws into the T nuts below – be careful not to over tighten – and the screws are used to adjust the threshold as well. Adjusting the Threshold: Once the threshold is installed and all screws are screwed into the T nuts - the threshold can be adjusted by tightening or loosening the screws. Tightening screws to lower the threshold or loosening the screws to it rise up. Known Part Number: 203516, 203515, 203514, HHPD43

Read more less

Part Number: S4115 Peachtree W&F Peachtree Citadel Swing Patio Door Multipoint Lock Aux Module This is designed to be field reversible. The latch is two stage, it operates first as a latch, then further extends to be a deadbolt. But the housing is symmetrical and the latch is removable. It  can be operated for Left hand or Right Hand, inswing or outswing swing doors. Associated Parts Sold Separately:  D301 W&F Trilennium multipoint 6 Inch CTC Replacement Handle Set S4112 - Peachtree Multipoint Mortise Lock Citadel IPD Citation W&F
