Parrt Number S4004.  Before you place your order please read below and watch our how to video at the bottom of the product page to make sure you order the correct hinge you need. Guide Horizontal Adjustable Door Hinge -  Guide Hinge For Left Hand and Right Hand Doors   S4004 is non handed you can change the handing before you install by removing the hinge pin (see picture). Hinge is made of Steel S4004 is a Guide Hinge - Horizontal adjustment only . Comes in multiple finishes S4004 works in tandem with S4003 sold separately. See hinge  placement diagram in pictures and watch our video at the bottom of the product page. S4004 is the direct replacement and interchangeable with Hoppe Columbus 2-D Hinge part # S4002 . Colors Available In Stock: Bright Brass, Brushed Chrome, White *See Finish Note Discontinued Colors: Oil Rubbed Bronze, Satin Nickel, Antique Brass , Black, Polished Chrome. (if you can add to cart we still have stock. Once stock is gone colors will be NLA and will not allow you to add to cart. No returns, all sales final on discontinued colors they are sold as is and have been marked down in price for quick sale). Condition: All hinges are NEW  any color with "As Is" added = New product that has been discounted due to one or more of the following: color or finish maybe discontinued, old stock,  minor finish flaws or scratches.  This item may be a customer return, vendor sample, or came in from the factory with finish flaws.  In some instances, these items are repackaged. All sales final. No returns on as is items. To order Set Vertical Adjustment Hinge See Part # S4003  Set and Guide Hinge Placement - Also See Hinge Placement Guide Drawing: 3 Hinges Per Door Panel: Starting at top of door Top of door Guide (Part # S4004) Set (Part # S4003) Guide (Part # S4004)   4 Hinges Per Door Panel: Anytime you need 4 hinges you would just add another guide hinge Starting at top of door Top of door Guide (Part # S4004) Guide (Part # S4004)  Set (Part # S4003) Guide (Part # S4004 Horizontal Hinge Adjustment Instructions:  Always Adjust your vertical hinge first, then adjust your horizontal hinge. Using a Philips screw driver, adjust the panel side to side, by turning clockwise to increase margins, Turn counter clockwise to decrease the margins.  Horizontal hinge has approximately 7 turns from its extremes. Automatic screwdrivers are NOT recommended. The speed of the gun may strip the heads of the screws are over adjusted.  Replacement hinge for hinges with(watch video below) Pat. Nr. 5701636, Pat. Nr. 5,701,636 Pro Tip: Remove weight from the hinges by lifting up on the door before you adjust. Never use power tools only use hand screw driver to adjust the door so you do not strip out the adjustment screws.  Matching Screws are included with each hinge. Known to work on: Roto, Semco Doors, Hoppe Hardware, Hoppe Columbus, Windsor Doors and Superior Doors, Loewen Doors and more *Finish Note: Not for Coastal or High Humidity Applications. These hinges do not come in a sea coast or stainless material, high humidity or costal application can cause hinges to corrode this is not a product defect. IF THIS HINGE DOES NOT LOOK EXACTLY LIKE YOUR ADJUSTABLE HINGE. CLICK HERE TO SEE ALL THE ADJUSTABLE HINGES WE HAVE ON OUR WEBSITE TO ORDER. IF YOU ARE NOT FINDING YOUR HINGE PLEASE EMAIL OR TEXT OUR RESEARCH DEPARTMENT AND WE WOULD BE HAPPY TO ASSIST YOU

Read more less

Part Number: S4010 Before you place your order please read all below watch our video at the bottom of the product page to make sure you order the correct hinge.  S4010 HTL Ultimate 2-D Hinge - Hoppe Guide Hinge Horizontal Adjustment - Non Handed -  Removable Pin Style No Screws Included  Color / Finish Options Are as Follows:  Bright Brass  Polished Chrome Rustic Umber  Stainless Steel  Matte Black White  Antique Brass, Brushed Chrome - NO LONGER AVAILABLE - Use part number S4012 as direct replacement hinge. When factory discontinues a color for S4010 use S4012 as the direct replacement hinge.  Product Description:  S4010 is a Guide Hinge - Horizontal adjustment only . Comes in multiple finishes S4010 works in tandem with S4009 sold separately. See hinge guide placement in pictures  Steel Reinforcements – Makes this new hinge the "Ultimate" with door systems.• Corrosion Resistant – Specially coated components for improveddurability and strength.• Easy Adjustment – Set hinge is Part # S4009 sold separately has a vertical adjustment feature (+/- 2.5mm). S4009 works in tandem with S4010. Guide hinge (Part # S4010) has a horizontal adjustment feature (+/- 2mm). See hinge placement diagram in pictures. • Maintenance Free Bearings – No oiling required.• Simple Door Preparation – Quick and easy one pass routing.• Variety of Finishes – Available in finishes to match your HOPPE® handle sets.• Designed to carry up to 165lbs. per door.• Not to be used in commercial applications, especially not inconjunction with a door closer. Set and Guide Hinge Placement:  3 Hinges Per Door Panel:  Starting at top of door Top of door Guide (S4010) Set (S4009)  Guide (S4010) 4 Hinges Per Door Panel: Anytime you need 4 hinges you would just add another guide hinge Starting at top of door Top of door Guide (S4010) Guide (S4010   Set (S4009) Guide (S4010)  The Set hinge no matter what is always the 2nd from the bottom Pro Tips: These hinges are not handed! The pin is removable So you can reverse the handing for your door . (Scroll thru pictures above that show this) Pin can be tight - use a flat head screw driver and hammer to LIGHTLY tap out the pin from the bottom. Remove weight from the hinges by lifting up on the door before you adjust.  Never use power tools to adjust the hinge. ONLY use hand tools.  Hinge: S4010 Minimum of two per panel. These hinges only have the horizontal adjustment ± 2mm. When the vertical adjustment (S4009) is turned clockwise, the non-adjustable leaf will move in the direction of the arrow. The vertical adjustment has 32 turns from it's extremes, and the horizontal (s4010) has 7 turns. Adjust the horizontal by turning clockwise to increase the margins. Turn counter clockwise to decrease the margins Known Part # 850-8762435,  850-8762531, Pat.Nr. 5.701.636, 30033, 8762531, 5 310544 0 10708

Read more less

Part Number S4003 - Vertical Adjustment  Before you place your order please read all below and watch our video at the bottom of the product page to make sure you order the correct hinge. Adjustable Door Hinge -  Set Hinge With Non-removable pin - Vertical Adjustment  Non Handed - these hinges are for Left Hand and Right Hand Doors, by removing the set screw and hinge pin and changing the handing before you install it on your door. S4003 is a Set hinge- vertical adjustment only . Comes in multiple finishes. Pin is removable. S4003 works in tandem with S4004 sold separately. See hinge placement diagram in pictures and watch video below. Colors Available In Stock: Bright Brass, Brushed Chrome, White *See finish note below Discontinued Colors: Oil Rubbed Bronze, Antique Brass , Black, Satin Nickel, Polished Chrome. (if you can add to cart we still have stock. Once stock is gone colors will be NLA and will not allow you to add to cart. No returns, all sales final on discontinued colors they are sold as is and have been marked down in price for quick sale). Condition: New - All hinges are new product As Is = any color with "AS IS" added is a New product that has been discounted due to one or more of the following: old stock, discontinued colors or styles,  minor finish flaws or scratches.  This item may be a customer return, vendor sample, or came in from the factory with finish flaws.  In some instances, these items are repackaged. Not available in all colors.  All sales final No returns on as is items. S4003 interchangeable and direct replacement for  Hoppe Columbus 2-D Hinge part # S4001 To Order Guide Horizontal Adjustment Hinge See Part # S4004 Set and Guide Hinge Placement - Also See Hinge Placement Guide Drawing: 3 Hinges Per Door Panel: Starting at top of door Top of door Guide (Part # S4004) Set (Part # S4003) Guide (Part # S4004) 4 Hinges Per Door Panel: Anytime you need 4 hinges you would just add another guide hinge Starting at top of door Top of door Guide (Part # S4004) Guide (Part # S4004)  Set (Part # S4003) Guide (Part # S4004) Vertical Hinge Adjustment Instructions:   Using a Phillips screwdriver, first adjust the panel up or down by turning the screw marked "V" on the set hinge. When turning the screw in the direction of the arrow (counter clockwise) the other leaf will be pushed in the direction of the arrow. Automatic screwdrivers are NOT recommended. The speed of the gun may strip the heads of the screws are over adjusted.  When the vertical adjustment is turned clockwise, the non-adjustable leaf will move in the direction of the arrow. The vertical adjustment has approximately 32 turns from its extremes. Replacement hinge for hinges with(watch video below) Pat. Nr. 5701636, Pat. Nr. 5,701,636 Pro Tip: Remove weight from the hinges by lifting up on the door before you adjust. Known Brands: Hoppe Hardware, Hoppe Columbus, Semco, Windsor Doors and Superior Doors, Loewen Doors, Roto and more. Matching Screws are included with each hinge. *Finish Note: Not for Coastal or High Humidity Applications. These hinges do not come in a sea coast or stainless material, high humidity or costal application can cause hinges to corrade this is not a product defect. IF THIS HINGE DOES NOT LOOK EXACTLY LIKE YOUR ADJUSTABLE HINGE. CLICK HERE TO SEE ALL THE ADJUSTABLE HINGES WE HAVE ON OUR WEBSITE TO ORDER. IF YOU ARE NOT FINDING YOUR HINGE PLEASE EMAIL OR TEXT OUR RESEARCH DEPARTMENT AND WE WOULD BE HAPPY TO ASSIST YOU How to Adjust video below updated 7/12/23

Read more less

Part Number: S4009 Before you place your order please read below and watch our video at the bottom of the product page to make sure you are ordering the correct hinge. Hoppe HTL Ultimate 2-D Hinge - Hoppe Set Hinge (vertical adjustment) - Removable Pin Style These SET HINGES ARE NOT HANDED - you can remove the pin to swap the handing for your door. (For NON-Removable pin style see Part # S4011 and they ARE HANDED, if any of the S4009 become unavailable you will need to order S4011) No Screws Included, sold individually  Material: Steel Color / Finish Options Are as Follows:  Bright Brass  Polished Chrome Rustic Umber  Matte Black (available for pre-order will not be receiving more in till mid October 2023, no order cancellation - thank you for your patience).  Stainless Steel  White  Antique Brass, Brushed Chrome - NO LONGER AVAILABLE once stock is gone See part number S4011 direct replacement hinge We stock these hinges- if you would like a QTY check on a color please e-mail or text us. Product Description:  S4009 is a Set hinge- vertical adjustment only . Comes in multiple finishes. Pin is removable. S4009 works in tandem with S4010 sold separately. See hinge placement diagram in pictures and watch video below. Steel Reinforcements – Makes this new hinge the "Ultimate" with door systems. • Corrosion Resistant – Specially coated components for improved durability and strength. • Easy Adjustment – Set hinge (Part # S4009) has a vertical adjustment feature (+/- 2.5mm) Guide hinge (Part # S4010 sold separately ) has a horizontal adjustment feature (+/- 2mm) and works in tandem with S4009 see hinge placement description below and diagram in pictures. • Maintenance Free Bearings – No oiling required. • Simple Door Preparation – Quick and easy one pass routing. • Variety of Finishes – Available in finishes to match your HOPPE® handle sets. • Designed to carry up to 165lbs. per door. • Not to be used in commercial applications, especially not in conjunction with a door closer.   Set and Guide Hinge Placement (see picture diagram): 3 Hinges Per Door Panel: Starting at top of door Top of door Guide (use part # S4010) Set (use part # S4009) Guide (use part # S4010)   4 Hinges Per Door Panel (see picture diagram): Anytime you need 4 hinges you would just add another guide hinge Starting at top of door Top of door Guide (use part # S4010) Guide (use part # S4010)  Set (use part # S4009) Guide (use part # S4010) The Set hinge no matter what is always the 2nd from the bottom Pro Tip: Remove weight from the hinges by lifting up on the door before you adjust.  Pro Tips: Remove weight from the hinges by lifting up on the door before you adjust.  Never use power tools to adjust the hinge. ONLY use hand tools.  Hinge S4009- 1 hinge per panel. Vertical adjustment  feature (+/- 2.5mm) When the vertical adjustment (S4009) is turned clockwise, the non-adjustable leaf will move in the direction of the arrow. The vertical adjustment has 32 turns from it's extremes, and the horizontal (s4010) has 7 turns. Adjust the horizontal by turning clockwise to increase the margins. Turn counter clockwise to decrease the margins Known Part # 850-8762439 and Pat. Nr. 5701636, Pat. Nr. 5,701,636

Read more less

Part Number 825 Hoppe Single Point Gear Box as shown in pictures and in product video **** 825 Single point gear box is not interchangeable with multi point gear box system interior components are different see video**** In stock: Only part # 825-D which has a 1 3/4" Backset and 1" Dead Bolt Throw Special Order: All other part numbers are special order items (no returns or order cancellations) and can have a 1-4 week lead time once you place your order.   Strike is reversible for both left hand and right hand doors (see video below or revering latch instructions)  Install Instructions: Remove set screws on handle levers and remove Remove mounting screws on faceplate estuation of the handle set On side of door remove screw that lines up with the lock cylinder. Remove the handle set Remove all screws down the side of the door that holds on the gear box (keep all screws you will reuse them) Install new multipoint with screws Test for Operation  Reinstall handle set Test for proper operation

Read more less

Part Number 810  Pin/Roller and Flipper/Tongue Style Hoppe Multi point for Hurd Swinging Patio Doors only! (If your door is another door brand please email us and we can email you a worksheet you ok will need to fill out to get you the correct Hoppe multipoint for your door. info@windowpartscenter.com) Brass color no longer manufactured - only comes in stainless steel for both the gear box and the extensions.  Comes with: bottom extension with gear box attached and the top extension (choose your door height size). The Hoppe #810 Roller style is the direct replacement for old FUHR Roller Multi point that was on Hurd doors – no modification is needed when changing to the Hoppe #810. The only difference is some of the FUHR multi point had an automatic fire to engage the multi point, the Hoppe does not. So with the Hoppe to engage the multi point you close the door then lift up on the door handle then throw the dead bolt to lock. Hoppe Roller Style will also replace the Old FUHR Roller style. Top Extension: Comes in Door Heights: Retro/6-8, 6-10, 7-2, 8-0. This usually ships via UPS Ground. Style Options: Hoppe Gear Box Pin/Roller Style Hoppe Gear Box Flipper/Tongue Style Hurd Door Panel Heights for Top Extension:77" = Retro/6-878" = Retro/6-880" = 6-1084" = 7-293" = 8-0For Classic Hurd Doors Manufactured from 2005 and PriorFuhr Multi point used on Classic Hurd doors are no longer manufactured - Hoppe Multi point is the direct replacementNumber Known To Have Been On Older Gear Box (Hoppe Roller Style Brass Color): 1334291 - this is a component number.  Install Instructions (also see instructions in pictures): Remove set screws on handle levers and remove remove three mounting screws on faceplate estuation  On side of door remove screw that lines up with the lock cylinder. Remove the handle set Remove all screws down the side of the door that holds on the multipoint system (keep all screws you will reuse them) Install new multipoint with screws Test for Operation  Reinstall handle set Test for proper operation

Read more less

#813 - Hoppe 3Pt Convert Auto Release Striker - Bright Brass   Replacement Parts for Hoppe Multipoint Hardware used on swinging patio doors May have minor scuffs, etc these come this way from the factory not considered a defect.  Known To have Been Used On: Hurd, Weather Sheild, Hoppe, Marvin BiltBest and many other door brands that used Hoppe Multi Point Hardware  Sold Separately Are Part Numbers:     #833 - Hoppe 3Pt Convertible Under plate #834 - Hoppe 3Pt Striker For Rollers - Auto

Read more less

Part Number: SP40001 Hoppe Thumb Turn Shaft Bushing Washer and Spindle Fork Thumb Turn Shaft Replacement part for: For Hoppe HLS 9000 Multipoint Sliding Door handle Crescent Thumb Turn Sliding Patio Door handle Set (not included) Style: Shaft Only STOCK or Kit SPECAIL ORDER What's Included In Shaft Only 1 Shaft What's Included In Kit( SEPCAIL ORDER NO RETURNS):  1 Bushing 1 Washer  1 Spindle Fork Thumb Turn Shaft (also called Thumbtrun Shaft Coupling) To Have Been Used on: Hoppe HLS 9000 Genoa and Verona, Sierra Pacific CA Sliding Patio Doors Known Part Numbers: HPS2070803BU / HPS2080737WS / HPS2061421SP To Install:  Remove Handles trim from door. Remove the set screw from the Crescent Thumb Turn  Replace the shaft Bushing, Washer and Spindle Fork Reattach Crescent Thumb Turn with set screw (set screw will insert into hole opposite side of the prong fork end of the spindle). Reinstall handles set trim Hoppe HLS 9000 Multipoint Sliding Door handle Installation Instructions (you will be redirected to Hoppe website) Accessories Sold Separately:  Crescent Knob Cylinder Knob Set Screw HLS 9000 Sliding Door Hardware

Read more less

Part Number: 1000 Hoppe Arrone French Casement Hardware Connector Shaft 29.5MM - Lock Latch Shaft Length:  29.5 MM shown in pictures and in stock. 20.5MM 24 MM 20.5mm and 24 mm are NOT STOCKED can have a lead time of 2-3 weeks MM conversion to Inches:  20.5mm which is approximately 13/16 inches long 24mm – approximately 15/16” long 29.5 MM shaft version – shaft is approximately 1 5/32” long  This connector shaft has been known to have been used on Hurd, Sierra Pacific, Marvin and more French Casement Windows. Replacement option for old FUHR hardware that was bought out by Hoppe Bulk Pricing Shown In My Cart: QTY 2-5 10% off QTY 6+ 20% off Part Number: 1000, 3849093 Known To have Been used on Hurd, Sierra Pacific, Marvin, Pozzi and More. Related Parts Sold Separately:  Part Number 1000 - French Casement Connector Shaft FC Adaptor Part Number 1001 - French Casement Handle 33MM (1.5") Shaft  Part Number 1002 - French Casement Mounting Plate Part Number 1003 - French Corner Drive VS S-ES A0055 Part Number 1004 - French Casement Eurogroove Cover, Long Part Number 1005 -  French Casement Eurogroove Cover, Short Part Number 1006 - French Casement Gear S-ES 115/16 2MV FH Part Number 1007 - French Casement FC Linkage Part Number 1008 - French Casement Strike Lead-In S-ES Part Number 1009 - French Casement Strike
