Part Number C10000M
Interlock ASSA ABLOY Tru Latch Pro Latch Mechanism Only. Replacement Part
The original standard in automatic sash lock solutions for hung and sliding windows.
PRO-Latch features a removable cover and the ability to provide cost-effective proprietary aesthetics as well as architectural finishes. Whether you’re looking for a composite or metal cover, or a mechanism that is surface mounted or recessed into the profile, Interlock’s PRO-Latch is the highly customizable sash lock system that delivers superior performance.
Dimension: 2 7/8 Inch
Sold Individually (for large orders of QTY 100 and QTY 300 this will be considered special order item no returns)
Interlock US PAT NO 7,407,119 stamped on Mechanism
Manufacture Features
Removable snap-on cover (composite or metal options)
Fits most sliding and hung window applications
Multiple fixing locations available
Hurricane rated in impact-certified applications
Robust dual hooks for superior FER resistance
Surface mounted or recessed into profile
Patented cover design
Manufacture Specifications
± 2.032 mm (0.080”) of misalignment tolerance in all directions
± 2.032 mm (0.080”) – ±4.064 mm (0.160”) of lateral adjustment
depending on keeper design
Passes all required FER testing requirements for sliding
and hung windows
Designed for Dade County impact window applications
Has exceeded 145 kg (320 lbs) per lock in a pull test
Endurance tested to 36,000 operating cycles
Minimum 1,000 hours Neutral Salt Spray resistance
Parts Sold Separately:
Mechanism: Part Number C10000M
Mechanism Screws: Part Number C10000MS
Cover: Concealed Screw Cover Part Number C10000CSC
Cover: ADA with pull string Part Number C10000ADAC
Cover: With Exposed Screw Cover Part Number C10000ESC
Cover: Slimline Composite or Zinc Cover Part Number C10000SLC
Cover: With Exposed Screw Cover Part Number C10000ESC
Keeper: Face Mounted Striker Keeper Part Number C10000FMK
Keeper: Surface Striker Keeper Part Number C10000SSK
Keeper Screes: Part Number C10000KS
Replaces old Part number: C1000NS
Part Number: C10000 This page is for information only and shows which part numbers work together and options:
Interlock Pro-Latch Auto lock
Featuring automatic locking action and a removable cover, Pro-Latch offers the ability to provide cost-effective proprietary aesthetics as well as architectural finishes.
To Order See the Following Part Numbers:
Mechanism: Part Number C10000M
Mechanism Screws: Part Number C10000MS
Cover: Concealed Screw Cover Part Number C10000CSC
Cover: ADA with pull string Part Number C10000ADAC
Cover: With Exposed Screw Cover Part Number C10000ESC
Cover: Slimline Composite or Zinc Cover Part Number C10000SLC
Cover: With Exposed Screw Cover Part Number C10000ESC
Keeper: Face Mounted Striker Keeper Part Number C10000FMK
Keeper: Surface Striker Keeper Part Number C10000SSK
Keeper Screes: Part Number C10000KS
The original standard in automatic sash lock solutions for hung and sliding windows.
PRO-Latch features a removable cover and the ability to provide cost-effective proprietary aesthetics as well as architectural finishes. Whether you’re looking for a composite or metal cover, or a mechanism that is surface mounted or recessed into the profile, Interlock’s PRO-Latch is the highly customizable sash lock system that delivers superior performance.
Features
Removable snap-on cover (composite or metal options)
Fits most sliding and hung window applications
Multiple fixing locations available
Hurricane rated in impact-certified applications
Robust dual hooks for superior FER resistance
Surface mounted or recessed into profile
Patented cover designs
Style:
Slim Line Cover: A clean, sophisticated aesthetic design to enhance the look of any window, this cover is supplied separate from the PRO-Latch mechanism. Two piece installation and is available in composite.
Exposed Screws Cover: The classic aesthetic design to compliment any window, this cover is supplied with the PRO-Latch mechanism installed in the cover for the convenience of a one piece installation.
Concealed Screws Cover: With a classic aesthetic design to complement any window, this cover is supplied separately from the mechanism in order to conceal the screws and achieve a sleek, sophisticated look. Cover is supplied separate from the PRO-Latch mechanism. Two piece installation
ADA Cover: The classic aesthetic design of our Concealed Screws Cover, with an adjustable pull cord to disengage the lock. Designed for easy operation and ADA compliancy. Cover is supplied separate from the PRO-Latch mechanism. Two piece installation
Size (striker keeper):
Face Mounted Striker Keeper Mounted on a vertical wall on the profile
Surface Striker Keeper Mounted on a horizontal wall on the profile
Interlock US PAT NO 7,407,119 stamped on Mechanism
Part Number C10000ADAC
Interlock ASSA ABLOY TRU-Latch Pro Latch Cover ADA with pull string
The original standard in automatic sash lock solutions for hung and sliding windows.
The classic aesthetic design of our Concealed Screws Cover, with an adjustable pull cord to disengage the lock. Designed for easy operation and ADA compliancy.
Sold Individually ADA Cover Only (for large orders of QTY 100 and QTY 300 this will be considered special order item no returns)
Color: White, Black, Almond (aka Beige)
Material: Composite
Interlock Part Series: 5f798
Parts Sold Separately:
Mechanism: Part Number C10000M
Mechanism Screws: Part Number C10000MS
Cover: Concealed Screw Cover Part Number C10000CSC
Cover: ADA with pull string Part Number C10000ADAC
Cover: With Exposed Screw Cover Part Number C10000ESC
Cover: Slimline Composite or Zinc Cover Part Number C10000SLC
Cover: With Exposed Screw Cover Part Number C10000ESC
Keeper: Face Mounted Striker Keeper Part Number C10000FMK
Keeper: Surface Striker Keeper Part Number C10000SSK
Keeper Screws: Part Number C10000KS
(Interlock US PAT NO 7,407,119 stamped on Mechanism )
Part Number S1016
ASSA ABLOY Casement Window Operating Control Device WOCD KIT with Stickers!
Packed and Sold as Kit. Kit Contains:
One (1) 11.1mm Pin Strike
One (1) Latch ( Your choice of: Left Hand or Right Hand and 4 inch or 6 inch long)
Four (4) mounting Screws
One (1) Operational Sill Sticker
One (1) Indication Glass Sticker
One (1) Installation Instructions.
ASSA ABLOY Casement Window Operating Control Devise WOCD KIT
The ultimate solution in residential window safety is now available with the connivance of an all-inclusive kit. Easy to fit with no routing required, m the ASSA ABLOY WOCD Kit is designed for use in windows with standard 11.1mm (7/16" hardware cavity).
Features:
4 inch in stock ( 6 inch Lengths available for special order email for quote)
Tested and compliant to ASTM F2090-13
Limits venting to less than 4" of opening
Comparable with standard countersunk fixing
Austenitic 304 stainless steel for enhanced corrosion resistance
Convenience of all-inclusive bagging kit for ease of installation
No fabrication required - cavity fitting
Part Number C1000
Auto Lock has been discontinued my manufacturer the retro fit replacement style by the Interlock Slimline Lock (see picture) C10000 or S1111 links under accessory items. These will directly replace the old Auto lock only 2 new holes will need to be drilled on the sash (see video). To order replacement lock use C10000 series - click here to see all options
Auto Lock Replacement For WinPro and Cascade Series 9100 Horizontal Slider and 9200 Single Hungs and customers have also said this replacement locks works on Mercer auto locks as well Color: White
Used on multiple window lines including Cascade (9/5/2017 and older), Mercer and others
Part Number C10000SLC
Interlock ASSA ABLOY TRU-Latch Pro Latch Slimline Composite or Zinc Cover 5F798
The original standard in automatic sash lock solutions for hung and sliding windows. Sash Lock Cover
Slim Line Cover: A clean, sophisticated aesthetic design to enhance the look of any window, this cover is suppliedseparate from the TRU-Latch mechanism and is available in composite or zinc.
Sold Individually Exposed Screw Cover comes with Mechanism together see pictures: (for large orders of QTY 100 and QTY 300 this will be considered special order item no returns)
Color: White Almond (aka beige), Clay and Black
Material: Composite or Zinc
Interlock Part Series: 5f798
Parts Sold Separately:
Mechanism: Part Number C10000M
Mechanism Screws: Part Number C10000MS
Cover: Concealed Screw Cover Part Number C10000CSC
Cover: ADA with pull string Part Number C10000ADAC
Cover: With Exposed Screw Cover Part Number C10000ESC
Cover: Slimline Composite or Zinc Cover Part Number C10000SLC
Cover: With Exposed Screw Cover Part Number C10000ESC
Keeper: Face Mounted Striker Keeper Part Number C10000FMK
Keeper: Surface Striker Keeper Part Number C10000SSK
Keeper Screes: Part Number C10000KS
(Interlock US PAT NO 7,407,119 stamped on Mechanism )
Part Number C10000FMK
Surface Fixed Striker Keeper (Face Mount Keeper) for Single Hung, Double hung and Horizontal Slider Window lock..
Sold Individually (for large orders of QTY 100 and QTY 300 this will be considered special order item no returns)
Color: White, Clay, Almond (aka Beige)
Parts Sold Separately:
installation jig: S1111JMechanism: Part Number C10000M
Mechanism Screws: Part Number C10000MS
Cover: Concealed Screw Cover Part Number C10000CSC
Cover: ADA with pull string Part Number C10000ADAC
Cover: With Exposed Screw Cover Part Number C10000ESC
Cover: Slimline Composite or Zinc Cover Part Number C10000SLC
Cover: With Exposed Screw Cover Part Number C10000ESC
Keeper: Face Mounted Striker Keeper Part Number C10000FMK
Keeper: Surface Striker Keeper Part Number C10000SSK
Keeper Screws: Part Number C10000KS
Mechanism: Part Number S1111M
Flip lock Keeper: Part Number S1111FLC
Part Number C10000SSK
Surface Striker Keeper for single hung, double hung and horizontal slider window locks
Sold Individually (for large orders of QTY 100 and QTY 300 this will be considered special order item no returns)
Color: White, Black, Almond (AKA Beige), Almond MK, Blue White
Known Accessory Parts Sold Separately:
installation jig: S1111J
Mechanism: Part Number C10000M
Mechanism Screws: Part Number C10000MS
Cover: Concealed Screw Cover Part Number C10000CSC
Cover: ADA with pull string Part Number C10000ADAC
Cover: With Exposed Screw Cover Part Number C10000ESC
Cover: Slimline Composite or Zinc Cover Part Number C10000SLC
Cover: With Exposed Screw Cover Part Number C10000ESC
Keeper: Face Mounted Striker Keeper Part Number C10000FMK
Keeper: Surface Striker Keeper Part Number C10000SSK
Keeper Screws: Part Number C10000KS
Mechanism: Part Number S1111M
Flip Lock Cover: S1111FLC
524-005 Adams Rite / Assa Abloy Sliding Patio Door Handle Metal Latch Plate
Manufacturer: Adams Rite / Assa Abloy
Over All: 3 15/16" Long x 53/64" Wide
Middle Rectangle Offset cut out: 1" long
Top of strike to top of offset middle rectangle cut out: 1 -11/16"
Discontinued Product. What we have in stock is all that is available. Sold as is no returns all sales final.
Part Number C10000ESC
Interlock ASSA ABLOY TRU-Latch Pro Latch Cover With Exposed Screw Cover 5F798
The original standard in automatic sash lock solutions for hung and sliding windows. Sash Lock Cover
With a classic aesthetic design to complement any window, this cover is supplied with the mechanism with exposed screws holes.
Sold Individually Exposed Screw Cover comes with Mechanism together see pictures: (for large orders of QTY 100 and QTY 300 this will be considered special order item no returns)
Material: Composite
Color: White only
Interlock Part Series: 5f798
Parts Sold Separately:
Mechanism: Part Number C10000M
Mechanism Screws: Part Number C10000MS
Cover: Concealed Screw Cover Part Number C10000CSC
Cover: ADA with pull string Part Number C10000ADAC
Cover: With Exposed Screw Cover Part Number C10000ESC
Cover: Slimline Composite or Zinc Cover Part Number C10000SLC
Cover: With Exposed Screw Cover Part Number C10000ESC
Keeper: Face Mounted Striker Keeper Part Number C10000FMK
Keeper: Surface Striker Keeper Part Number C10000SSK
Keeper Screws: Part Number C10000KS
(Interlock US PAT NO 7,407,119 stamped on Mechanism )
Part Number: S1111J
Lock Keeper Installation Jig for Double Hung, Single Hung and Horizontal Slider Window Keepers
Color: Red
Works with the following Keeper Striker:
C10000FMK - Face Mount Keeper
C10000SSK - Surface Striker Keeper (Surface Mounted)
Accessories Sold Separately:
C10000FMK - Face Mount Keeper
C10000SSK - Surface Striker Keeper (Surface Mounted)
S1111M - Mechanism
S1111FLC - Flip Lock Cover
Mechanism: Part Number C10000M
Mechanism Screws: Part Number C10000MS
Cover: Concealed Screw Cover Part Number C10000CSC
Cover: ADA with pull string Part Number C10000ADAC
Cover: With Exposed Screw Cover Part Number C10000ESC
Cover: Slimline Composite or Zinc Cover Part Number C10000SLC
Cover: With Exposed Screw Cover Part Number C10000ESC
Can also be used as a replacement retro fit lock for Cascade and Mercer old auto lock. - Watch video below in full- you will need to drill 2 new mounting screw holes! Part number C10000 is what is shown in the video below.
Part Number C10000CSC
Interlock ASSA ABLOY TRU-Latch Pro Latch Cover Concealed Screw Cover 5f798
The original standard in automatic sash lock solutions for hung and sliding windows. Sash Lock Cover
With a classic aesthetic design to complement any window, this cover is supplied separately from the mechanism in order to conceal the screws and achieve a sleek, sophisticated look.
Sold Individually Cover Only (for large orders of QTY 100 and QTY 300 this will be considered special order item no returns)
Colors: White, Black and Almond (aka Beige)
Material: Composite
Interlock Part Series: 5f798
Parts Sold Separately:
Mechanism: Part Number C10000M
Mechanism Screws: Part Number C10000MS
Cover: Concealed Screw Cover Part Number C10000CSC
Cover: ADA with pull string Part Number C10000ADAC
Cover: With Exposed Screw Cover Part Number C10000ESC
Cover: Slimline Composite or Zinc Cover Part Number C10000SLC
Cover: With Exposed Screw Cover Part Number C10000ESC
Keeper: Face Mounted Striker Keeper Part Number C10000FMK
Keeper: Surface Striker Keeper Part Number C10000SSK
Keeper Screws: Part Number C10000KS
(Interlock US PAT NO 7,407,119 stamped on Mechanism )
