Marvin

Part Number: 815 / 816 Vertical and Horizontal Adjustable Door Hinge Hinges are handed! Match up your existing hinge to picture to determine what handing you need. Finishes:  In Stock: If you order more than what we have in stock the order will be considered pre-order and will ship out as soon as we receive in from the factory. If you would like what we have in stock partial shipped please leave a note in not comment section of your order stating to partial ship.  Pre-Order: If finish is a pre-order we will ship out as soon as we receive in from the factory. lead times can very but can be 6-8 weeks   Discontinued Finishes: Goldtone, Brushed Chrome and True Oil Rubbed Bronze. Limited stock available. The discontinued colors we have in stock may have some minor scratches - no returns or exchanges, they are sold as is. Once our stock is gone we will be unable to get more. Dimensions: Over all 3 3/4" W x 4 1/4" H Condition:  New - New product - unused  As Is - New product with finish flaws or scratches.  This item may be a customer return, vendor sample, or came in from the factory with finish flaws.  In some instances, these items are repackaged. Not available in all colors or handing.  All sales final, No returns.  Screw Pack: Screws are sold separately and not all colors are available. To order Screws with your hinges see 815/816 Screw Pack (1 screw pack will do 1 hinge). Or you can buy at your local hardware store the following: QTY 4 - #9 x 3/4" or 1” PH Screw (size change depends on what finish the screw is available in) QTY 4 - #7 x 1-1/4" PH Screw QTY 1 - #9 x 2-1/2” or 3” PH Screw (size change depends on what finish the screw is available in) Link To Hinge Adjustment Instructions Number to be found on back of Leaf 903 and on back of adjustable side of hinge 921. These hinges have been known to be used on Hurd Patio doors and BiltBest Patio Doors, Marvin Ultimate Inswing Patio Doors From 1993 - 1996 and other door brands. (Known part #: 815, 816 903, 291, 2443, 085439, 021791, 085442, 010294, 031239) IF THIS HINGE DOES NOT LOOK EXACTLY LIKE YOUR ADJUSTABLE HINGE. CLICK HERE TO SEE ALL THE ADJUSTABLE HINGES WE HAVE ON OUR WEBSITE TO ORDER. IF YOU ARE NOT FINDING YOUR HINGE PLEASE EMAIL OR TEXT OUR RESEARCH DEPARTMENT AND WE WOULD BE HAPPY TO ASSIST YOU.

Read more less

528 - Patio Door Replacement Screen Rollers  Part Number 528 - Replacement Screen Rollers - For Sliding Patio DoorsSize: See Photos for measurements. 2 Inch Long Overall  with 1" steel wheel-ball barring.Sold in: Set of 2 per pack 1 left and 1 right In Stock:  All Metal  Low QTY: White, Sand and Bronze are low stock discontinued item. If you can add to cart we have it in stock still. Once gone the all metal is the direct replacement. Screws: Replacement screws are sold separately Click Here to add to order If you want to replace both top and bottom rollers (total of 4 rollers) you will need to purchase QTY 2 packs. These parts are NEW- Marks found on roller adjustment are not defects. Rollers come pre packaged by the manufacturer. The “marks” you see on the sand and white adjustment are from the molds they use to make the parts and put them together. This parts were used on Hurd doors prior to 2006.Known Brands and Part Numbers: 025701, 025702, 025703, 23739000000, Hurd, Crestline, ParkVue, Merrill Millwork, Kolbe & Kolbe Millwork, Weather Shield, Peachtree Citadel Door Roller, Semco, Marvin and more. *Note to customer* there are a wide verity of rollers available. If the drawing does not look exactly like your tandem roller Click Here to see all rollers on our website. If you cant find the part you are looking for please email or text us a picture of your roller and our research team would be happy to assist you with finding the right one. Email: Info@WindowPartsCetner.com Text Line: 303-222-4489

Read more less

Part Number: 101 Amesbury Truth Maxim Dual Arm 50.00 DLX Sill Mount Casement Dual Arm Operator #101 101 Maxim DLX Sill Mount Style has been discontinued by manufacturer. Once our stock is depleted, you will order the replacement Encore Style Part # 119 and  You will need to purchase the cover and handle kit part number 137 sold separately. Colors in Stock for 101 Maxim Style: Goldtone ( once stock is gone you will have to order 119 Encore Style please watch videos below) To order 119 Encore style: go to 119 Encore Product Page - Part # 119 - Newer Encore Operators are a direct replacement/upgrade for these. See part number 119 You will also need to add to cart and order #137 cover and handle kit in the same handing Part Number: 137 Encore Folding Handle and Cover Kit PRODUCT TIPS Per Manufacturer 1. Operator base handing is determined by the window hinge side when viewed from the outside.2. Handing of Encore 119 Handle and cover is determined by the direction the handle points when in the nested position.3. Encore’s 119 unique spline design will only accept Tango or Encore specific handle designs.(See part number 137) (Note: This is part # 101  is the SILL MOUNTED version 7/16" measurement. For low profile version with 31/64" measurement see part number S1067 Amesbury Truth Maxim DLX Casement Dual Arm Low Profile Operator) Smooth and Curved appearance. Designed to operate sash size from 24" to 40" wide, 84" high and weighting up to 108 lbs.  101 Maxim: Older operators had black painted arms. Now arms are painted beige. Handle Sold Separately  Manufacturer Details: Exceptional Maxim Operators provide maximum performance to open and close larger windows with 33% less effort than previous operators. These operators feature a sealable housing to reduce water and air infiltration without the use of caulk or additional sealant. Available in a full range of operator styles, Maxim helps reduce manufacturing and inventory costs by using the same operator mounting location on every window size. An optional folding handle can be added. Stainless steel packages are available for demanding coastal applications. Developed as a system with Maxim Hinges and Locks to ensure maximum efficiency. Replacement Parts for: Hurd, Marvin, Cascade, Bilt Best, Milgard, Sierra Pacific, Allsco and more.  Related Products Sold Separately for Part Number 101 Maxim Operator :  Part # 177 – non folding handle Part # 131 – Folding handle option Part # 187 - Sash Bracket with Set Ring  - elbow arm of #101 operator snaps onto Part # 189 - Track Shoe – what the long arm of the #101 operator snaps onto Part # 114 - Sash Track (what the track shoe #189 slides into) Part # 121 - Adjustable Hinge – below the operator on the bottom and on top of the window when you open it. Part # 119 - Newer Encore Operators are a direct replacement/upgrade for these. See part number 119 Part Number 137 Associated Parts Sold Separately For Encore Style 119:  Part Number: 137 Encore Folding Handle and Cover Kit RECOMMENDED SCREWS: (QTY 6)(PN 19240.XX)#8 X 1 FLAT HEAD SHEET METAL SCREW (SEE TRUTH TIPS FOR MORE INFORMATION) (QTY 2)FOR REAR MOUNT:#8-32 X 3/8 PAN HEAD MACHINE SCREW PN 19545.XX Known Part Numbers: 101, 090937, 010724, 010723, 090938, 010725, 010722, 41012, 36-368-2, 36-369-2, 50.00.XX.011 14D500P to 14D800P and 6D700P, 50-00-32-011, 50-00-24-011, 50-00-32-012, 50-00-24-012, HCSE25, S3-2254, S3-2253, S3-2252, S3-2251, S3-2250, S3-2249, U3-2248, U3-2247, 50.00-RH-SS-CHA Known to have been used on the following Manufacture brand windows: Cascade, Sierra pacific Allsco, Marvin, Weather sheld Hurd DLX duel arm for casements manufactured 2/02/98 to 9/19/2005, and more Videos:  This video shows how the 119 with 137 cover and handle is the direct replacement for the 101 operator and how to install. This video shows how the sash track shoe and sash bracket disconnect from the 101 and 119 operator This video shows the difference below the Goldtone color and New Goldtone If you are not sure you can e-mail us a picture of your existing operator. Please read our Parts Identification Instruction page and then e-mail your pictures to: info@windowpartscenter.com

Read more less

Part Number 152 EntryGard (EntryGuard) Dual Arm Operator 5 17/64" (inch) Style Handing:  Left Hand Right Hand View pictures and how to video below (2:40 min) to determine handing you need. Measurements in Chart (Scroll Thru Pictures for Chart):  "A" Measurement in Drawing is 5 17/64" Circled in red in chart "B" Measurement in Drawing is 4 7/16"  circled in red in chart The other arm sizes are available for "A" and "B" measurements which can be ordered using our links below using our factory drop ship part catalog website (scroll thru pictures to see arm option chart for part numbers and See how to video below on how to read the chart).  Styles Available : Link Offset Up  Link Offset Down   Note: Detached clips can be revered in the field to be on top of bottom of arm. 152 will all come as Clip on the top. Finish:  E-Gard Handle and Cover Sold Separately See part # 139 for handle and #166 cover, S1002 Cover or upgrade to #S1004 for nesting handle and cover.  Known Part Numbers: 20910, L30941, 40853, U.S. PAT. 4,241,541 - CAN. PAT. 350,432 - PAT. 1982 , 31538, 40754, 45179, 40753, 31538A, 20810A, 15-63-00-002 15-63-00-001, MONCSE953, R3-2256, 53-2255  Replacement Parts for: Hurd, Semco, Marvin, Cascade, Caradco, BiltBest, Norco Milgard, Sierra Pacific, Allsco (1980 to Dec. 1997), Monarch Old Series and more. Other Arm Sizes Links to Order (this is an update to our video below). Watch video to see how to read chart in pictures above to determine your A and B Measurements match part numbers on chart to links below: Click here to order: 36-181 Click here to order: 36-182 Click here to order: 36-183 Click here to order: 36-184 Click here to order: 36-186 Click here to order 36-185 Info on our parts catalog factory direct website Cut Sheet For EntryGard Dual Arm 15 Series

Read more less

Part # 119 Casement Operator  - Encore Dual Arm Sill Mount Amesbury Truth 50.10  119 is the Operator Only - You will need to purchase the cover and handle kit part number 137 sold separately. Manufacture Details: Encore Operators give you all the strength and performance characteristics of Maxim, but with the flexibility of a snap-fit cover and streamlined full-flip folding handle that eliminates collapse during operation. Encore Operators require 33% less effort to operate than previous operators and are designed to use the same mounting location as the Maxim system. Stainless steel components are available for coastal applications. These operators complement the Encore Multi-Point Locking System.  Finish Arms available in: Standard E-Gard Beige (stock) and Stainless Steel (Non stock)* *Non stock items are special order and can have a 2-6 week lead time. orders can not be cancelled or returned.  Associated Parts Sold Separately:  Part Number: 137 Encore Folding Handle and Cover Kit Part # 187 - Sash Bracket with Set Ring  - elbow arm of #101 operator snaps onto Part # 189 - Track Shoe – what the long arm of the #101 operator snaps onto Part # 114 - Sash Track (what the track shoe #189 slides into) Part # 121 - Adjustable Hinge – below the operator on the bottom and on top of the window when you open it. Known to have been used on the following Manufacturing Brands:  Hurd, Semco, Marvin, Cascade,  BiltBest, Milgard, Sierra Pacific Monarch April 2006 to present  and more.   Manufacture Tech Note: Proper Installation of an Operator Cover & Nested Folding Handle. When installing the cover and handle on the operator you should follow theseinstructions:• Snap the cover onto the operator base.• Place the handle onto the spline of the operator and rotate the handle to closethe window.• Lock the window in place.• Rotate the handle Ľ turn back (towards opening direction) to reduce thepressure on the operator.• If the handle needs to be positioned in a nested cover you can remove thehandle at this time and re-position it so that it will rest correctly in the nestedcover.• Tighten the set screw on the handle.• Unlock the window and cycle the sash open and closed until the handle returnsto the starting position whereby there is no additional torque required to close the sash. Note: the sash should travel to a point that the lock can easily engageand seal the window.• If the window does not come all the way into the closed position, and more forceis required on the operator to close the window, you will need to review thewindow for the following; sash sag; racked window; lock points that are notproperly aligned; or hinges not installed correctly. These issues should becorrected prior to repeating the installation of the handle onto the operatorspline.Placing the operator and the handle under high stress and abusive loads can causepermanent failures to the handle or operator as the window is repeatedly opened andclosed. Known Part Numbers: 119, 096357, 096358, 36-368EN, 36-369-EN updated 7/8/23

Read more less

Part Number 166 EntryGard Replacement Covers Only - 10341 Amesburty Truth  Truth EntryGard Operator Contour Cover Only - Fits 15 Series EntryGard Casement and Awning Operator andHandles 139 and 135 sold separately  - See Accessories items Known Part Numbers On Operator: 20910, L30941, 40853, U.S. PAT. 4,241,541 - CAN. PAT. 350,432 - PAT. 1982 , 31538, 40754, 45179 Discontinued Color:  Coppertone. For Additional Entrygard Covers in different styles  and colors see part numbers S1002 and S1004  Replacement Parts for: Hurd, Semco, Marvin, Cascade, Caradco, BiltBest, Milgard, Sierra Pacific and more. Free Economy Shipping On All USA Orders. If Cover color or QTY you want to order is is out of stock you can pre-order and parts will ship out as soon as they come in from the factory.

Read more less

Part Number: 121 Amesbury Truth Adjustable Casement and Awning Hinge Track Kit Stack Hight: 7/16" (see picture)  What's included: 1 left hand hinge track with hinge arm, 1 right hand hinge track with hinge arm (universal for both left and right handed casement Windows - hinges are used on the top and bottom of the casement window swap which one goes in top and bottom depending on how your window is handed).  Size: 10 inch, 14 inch (determine your size by measuring the track).  Finish: Standard (beige E-Guard powder coat shown in pictures), Stainless Steel Hinge track kits are adjustable. To order adjustable wrench see part # 190 (sold separately). Only one wrench is needed for multiple hingesAdjustable hinges help with sash dragging. When you adjust the bottom hinge toward the locking side it raises up the lock side sash up. If it makes it worse adjust the other way. If you have the old style hinges with the metal clip you MUST also replace the track, which comes in the kit, as the new style hinge arms do not have a metal clip to hold it to the track. They now have a set ring on the track to hold everything in place. Old style hinges with clip are no longer available.  Known Part Numbers: 121, 30451, 30144, 30350, 20681, 30463, 31512, 31532, 14-77-00-009, 14-77-00-010 Associated Parts Sold Separately: part number 190: Hinge Adjustment Wrench

Read more less

Part Number: 131   Folding Crank Handle for Amesbury Truth 11/32 Spline OperatorsColors: Aluminum, Beige, Black, Bright White, Bronze, Chestnut Bronze, Clay, Faux Oil Rubbed Bronze, New Goldtone, Tuscan Bronze White  Special order Colors: Goldtone, Oil Rubbed Bronze, Bright Brass are a non returnable item- no returns for these items Large Quantities Order: orders with QTY 50 or more are special order items no returns or order cancellations.  Related Parts: Part # 101 Truth Maxim Dual Arm Casement Operator Part # 102 Truth Maxim Split  Arm Dyad Casement Operator Part # 209 Truth Maxim Awning Operator  Part # 111 Truth Ellipse Style Split Arm Dyad Casement Operator  Part # 105 Truth Ellipse Style Straight Arm Casement Operator  Other Amesbury Truth Operators  Part # 131 Folding Handle was primarily used on Part # 101, 102 and 209 Truth Maxim casement and awning operators). Replacement part for Hurd Casement and awing window operators Vintage Classic Style: 02/02/1998 - 9/17/2007. Also used on many other window brands that use Truth Hardware  Known Part Numbers: Truth, 45393, U.S. PAT. 351490, 5560082, 131, Truth 3, 037189, 037188, 091691, 11329-32, HCSE31, A3-2104, A4-2149, A4-2150, A4-2147, A4-2148, 00-0000  Replacement Parts for: Hurd, Semco, Marvin, Cascade, Caradco, BiltBest, Milgard, Sierra Pacific, Vetter, Allsco and more. Updated 7/24/23

Read more less

Part Number: 216 Crank Handle Adapter 5/8 Inch Hex Femail used with  Clear Story  Windows Size: Spline Size see list below 11/32 Spline Fits: Truth (Amesbury Truth): Marvin, Some Milgard, Caradco, Weather Shield, Hurd, BiltBest, Eagle, Vetter, Roto X Drive and Others 9/32 Spline Fits Peachtree and Getty 3/8 Special Spline Fits: Pella 3/8 Special Spline Fits: Anderson 3/8 Spline Fits: Some Milgard and Others Finish: Mill (Special order colors email for pricing: White, Black and Champagne)  Put those operable clerestory windows to energy-saving use with our 39-series clerestory extension crank. High mounted windows are excellent for capturing light while providing privacy, but they can also be “excellent” heat traps. It is now possible to vent the heat that rises to these areas as easily as opening any other window in the home.It’s inexpensive and can easily retrofit to existing or new window installations. By simple removal of the existing crank handle and replacement with an adapter (Hex-Bolt) the crank will open and close any operable clerestory window. It is not necessary to replace the current operator.The removable extension crank is available in many standard sizes for either sill or jamb mounted operators. (See Manual Window Wands) The standard finish for the crank is natural anodized aluminum.

Read more less

Part Number: 911 5/8" Snap-In-Vinyl Glazing Bead - for 5/8" overall glass thickness For 5/8" OA Glass Size: This item is sold individually in 6 foot lengths Color: White (when installed white is all you see) This item has bulk Price discounts. See chart. Dimensions: Long Leg 15/16 inch (goes under glass). Short leg 9/16 inch (the face of the glazing bead) Color: White Replacement parts for: Hurd, Rivco and Marvin Windows and Doors.  Also available in other sizes: Part number 912 - 3/4" Snap-In-Vinyl Glazing Bead Part Number 914 - 1" Snap-In-Vinyl Glazing Bead

Read more less

Part Number 115 50 Series with traditional housing has been discontinued. Direct Replacement is the 60 Series with Ellipse Operator Short Arm 9 1/2" Measurement is taken from center of housing to center of nylon roller - see drawing to measure accurately on your operator.  Amesbury Truth Single Arm 50 Series  Operator Short Arm 9 1/2" Color in picture: Goldtone To determine what handing to order: Look at picture of part and match up your operator to our picture to determine if you need to order a Left or Right handing. Click on picture to enlarge to see handing, color and dimension of operators PLEASE NOTE: Operators Old Square Style has been discontinued by manufacturer - once our stock is depleted we will automatically send the New Style which is the direct replacement. New Style Operator face is rounded rather than square. Known Part Number: 45251, 7707    Replacement Parts for: Hurd, Marvin, Cascade, Caradco, BiltBest, Semco, Oldach Operators with Similar Housing But Different Arm Lengths:  Part Number S1082 - Truth/Wright Dyad Operator Part Number S1048 - Truth/Wright Dyad operator Part Number S1068 - Truth/Wright Dyad Operator Part Number 105 - Truth/Wright Straight Arm Part Number 115 - Truth/Wright Straight Arm Part Number 109 -Truth/Wright Straight Arm Part Number 112 - Truth/Wright Straight Arm Part Number S1037 -GU - Split Arm Dyad Operator Part Number S1038 GU - Split Arm Dyad Operator Kit Part Number 111 - Truth/Wright Split Arm Dyad Operator  Known Part Number: 15-31-32-051, 15-31-32-052

Read more less

Part Number: 102 Amesbury Truth Maxim Casement DLX Split Arm / Dyad Operator 102 maxim series has been discontinued. Once stock is depleted the direct replacement will be 147 Encore Series. When you order 147 Encore  - You will need to purchase the cover and handle kit part number 137 sold separately. The Maxim Series Dyad Operator is designed for narrow windows, but will operate a frame width from 16” to 32”; height up to 72” and a sash weight of up to 55 lbs. Replacement Parts for: Hurd, Marvin, Cascade, Bilt Best, Milgard, Sierra Pacific, Allsco and more. Known Part Number: 102, 45352, Truth, 50-50-32-011, 50-50-24-011, 50-50-32-012, 50-50-24-012 To Order Direct Replacement Encore Style 147:  Part Number 147 Encore Dyad Operator Part Number: 137 Encore Folding Handle and Cover Kit Instructions on How To Replace Operator Click On Blog Link Associated Parts Sold Separately for Part Number 102 Maxim DLX Style  P# 131 (Folding Handle)  P# 177 (Non Folding Handle).   If you are not sure you can e-mail us a picture of your existing operator. Please read our Parts Identification Instruction page and then e-mail your pictures to: info@windowpartscenter.com
