Description
Part Number: SS20016
7900 Flush Mount Tilt and Lock Sash Lock - with wash feature. Ashland Hardware Systems ZX-11DT DualTech
Color: White or Beige (aka Almond)
Handing: Left Hand Or Right Hand - Locks are handed the under side of the lock is stamped with a L or R see pictures.
Kit comes with: 1 Lock (Left hand or right hand), 1 Face Mount Keeper and screws
Allows double hung or single hung windows to lock but also to tilt to wash outside of window or remove sash.
Engineered for Performance
• All zinc die-cast sash lock construction for maximum strength
• Sash weld is not compromised to significantly increase corner strength
• Helps your window system meet the highest industry standards: – ASTM F588 (Grade 10) forced entry resistance test – California CAWM 301 forced entry resistance test – Tested to DP-50 performance levels
• Intuitive functionality allows latch to operate with a swing of the lock lever
• Positive detent in both the lock and unlock positions
Used on: SuperSeal Preminum Vinyl , Hurd and Sierra pacific VINYL 8000/8500 SERIES PREMIUM DOUBLE HUNG, MI Windows Restoration Series V5500
Associated Parts Sold Separately:
Known Component Part Number: ZX-11DT, Part number stamped on back of keeper: ID14170, 13867, 13875, 14354, A6560, 13866, 13970, 13874, 14353
