Swinging Patio Door Parts

Part Number: S4018 G-U Door Catch 12MM FL - Centered Timber Window and Door Catch  Btl. Türschnapper 12 mm FalzLuft Bullet-catchEuro-rebate 18 x 8 and 20 x 8, AX 9 Packs are the following: 1 pack = Comes with 1 bullet-catch and 1 bullet-catch roller-cam 2 pack = Comes with 2 bullet-catch and 2 bullet-catch roller-cam 5 pack = Comes with 5 bullet-catch and 5 bullet-catch roller-cam 10 pack = Comes with 10 bullet-catch and 10 bullet-catch roller-cam (best price) 25 pack = Comes with 25 bullet-catch and 25 bullet-catch roller-cam Part number on back of part 6-32819

Read more less

Part Number: S4203 GU FERCO BKS Middle Keeper Latch and Dead Bolt Strike Plate Swing Door Accessory  Size: 45 mm (1 3/4 inch) or 57 mm (2 1/4 Inch) Thick Doors Color: Dark Bronze PC, Stainless Steel, Polished Brass (not all colors are in stock you can email or text to check stock and ETA) Additional Information: Non-handed  With clear protective film Two #8 x 5/8 FH/PH screws included  For use with GU-SECURY S-Bolt active door lock (single door only) Known Part Numbers: 9-C4777-45-0-*, 9-C4777-57-0-*

Read more less

Part Number D308 The old style with the groove in the middle is no longer available. the replacement that you will receive is solid. -See pictures.  Mortise Lock Drive Rods Handset Spindles Shaft Pack of 2 7 mm square x 18 mm long For Trilennium, W&F and Endura handle sets   Known Pat. NO. On Handle Set: 4.671.089

Read more less

Ashland Sentinel MultiPoint Swing Door Lock System Facemount Active Lock Versions - Product Information page Product Information page. We do not stock this at our Denver warehouse.  - Use links in blue  under "Versions" subheading below to see pricing and to order your version - Available to Order via our parts catalog website  Versions: Model 56-100 Facemount Active Lock Welded Steel Deadbolt - Click Here to Order Model 56-185 Facemount Active Lock Powdered metal Deadbolt - Click here to Order Key Features of 56-100 and 56-185 Made from the finest 300 series stainless steel for superior corrosion resistance Incorporates the "Baby-Sitter Effect" that allows the consumer to operate the dead bolt and extension bolts independently of each other, eliminated the necessity for the consumer to lift the lever handle and engage the shoot bolts before activation the dead bolt. Incorporates an" Anti-Slam" device that prevents the lock bolts from extending until the door is in the closed position, eliminating the potential for door frame damage by the consumer. The shoot and dead bolts extend a full one-inch to meet the highest leaves of structural testing, and meets most local building codes. Performance and Security of 56-100 and 56-185 Mechanism has anti-backdrive provision on the deadbolt and shoot bolts to help prevent tampering. The extension bolt incorporates the necessary lead-in to provide signification pull-in of the door. Facemounted has .316" of pull in Robust and durable handle return spring design to prevent handle sag over time The handle is locked out when multipoint is in the locked position  Withstands abusive torques of over 500 lbs Lab tested over 50,000 cycles Manufacturing Flexibility and Ease The lock unit is one of the easiest and quickest to reverse the direction of the latch The very modular design gives flexibility to accommodate a variety of door sizes and options Lock has 2 3/8" backset Spacer sands offs are unitized to prevent the lock system from biding which mounting screws are accidently over tightened A simple one stop route profile for easier fabrication  easy peg-hole connection for quick installation Model 56-100P Multipoint Gearbox Passive - Click Here to Order Mortise type no astragal Has Deadbolt communication with the active panel lock When shoot bolts are extended and the active deadbolt is fully extended, the passive lock shoot bolts cannot be retracted. This prevents the homeowner from opening the passive panel with active deadbolt extended, which might damage the panel. Prevents active lock deadbolt from extending unless the passive shoot bolts are extended. Tells the homeowner to lock the passive panel first. Has latch communication with the active panel lock If the active deadbolt has not been engaged when passive lock shoot bolts are extended and the active lock latch is fully extended, the passive lock shoot bolts cannot be retracted. This prevents the homeowner from opening the passive panel first, which might damage the panel. Blocks active lock latch from full engagement into passive lock unless the passive shoot bolts are extended. Prevents damage to panels should passive panel be opened first and tells the homeowner to lock the passive panel first.  Model 56-480 Multipoint Gear Box Passive - Click Here to Order After shoot bolt extension, it has a thumb turn mechanism to manually lock the passive shoot bots in the extended position. Requires a passive trimset that has a thumb turn. Has deadbolt communication like above if the astragal is thin enough to allow the deadbolt to engage the blocker. However, this is typically used for thicker  astragal applications with no communication with the active lock. Model 56-481 - Multipoint Gear Box Passive - Click Here to Order Communication with active lock deadbolt through a 5/8" thick astragal No latch communication   Known to have been used on Caradco French doors and many other swinging doors that used Ashland hardware.  Known Component Number On Gear Box: 3295 3183 3194 68 Known Patent No. 6,209,931

Read more less

Part Number: 848 GU Sill Strike Gasket For Swinging Doors sold individually- see chart for bulk pricing  Color: Black Known to be used on: GU, Hurd and Sierra pacific WI in-swinging wood/clad doors. Associated parts Sold Separately:  Part Number 847: Sill Sill Strike Plug Known to be used on: GU, Hurd and Sierra pacific WI in-swinging wood/clad doors.

Read more less

Part Number: 846 GU Head Strike Plate, Semi Active French Swinging Door Stainless Steel Screws Not Included Known to be used on: GU, Hurd and Sierra pacific WI in-swinging wood/clad doors.

Read more less

Part Number: 841 Semi Active Current Style  Amesbury Truth Sentry® .63 and Sentry® .03 For GU Multi Point Hardware SEMI ACTIVE HANDLE SET* Semi Active handle set has thumb turn, but no keyed lock- To be used on a secondary door panel on a French door  that has shoot bolts that are operated and locked into place by the handle set. 10 Inch Escutcheon NOTE TO CUSTOMER: As of March 20 2017 the OLD STYLE 8.9375 long Escutcheon was discontinued by the manufacture (mounting screw hole where 7 5/8" center to center) . The new style has 10" long Escutcheon (Mounting screw holes are 8 5/8" center to center). Note this height change does alter the placement of our mounting holes. Bottom mounting screw hole will be reused, but the customer will have to drill one new top mounting screw hole. The old mounting screw hole will be covered by the escutcheon.  All handle sets will be shipped with the new 10 inch taller escutcheon plates. Please note a new mounting hole will be necessary. Field instructions (see pictures)  Finish Options for Different Styles:  (All styles are not available in every finish color) Classic Escutcheon with Traditional Handle  Antique Brass Black (Matte) Bright Brass Brushed Chrome Champagne Oil Rubbed Bronze FB**  Polished Chrome Satin Nickel White Classic Escutcheon with Loft Handle  Antique Brass Brushed Chrome Oil Rubbed Bronze FB (forever bronze not true oil rubbed bronze that will change) Polished Chrome Satin Nickel White  Contemporary Escutcheon with Loft Handle Antique Brass Black (Matte) Bright Brass Brushed Chrome Oil Rubbed Bronze FB** Polished Chrome Satin Nickel White Squared Contemporary Escutcheon with Contemporary Handle  Antique Brass Black (Matte) Bright Brass Brushed Chrome Oil Rubbed Bronze FB** Polished Chrome Satin Nickel White Special Order Item. No returns exchanges or order cancellations once order has been placed. Please allow 2-3 week lead time.Used on Hurd Inswing and outswing patio doors all wood and wood clad 2006 - Present - Direct Replacement For 2005 models as well *For Active handle sets see part number 840 comes keyed with thumb turn and are for single door or the primary active door panel on a French door. *For dummy handle see part number 842 no operation no thumb turn - To be used on a secondary door panel on a French door that is fixed in place with no operation or has manual shoot bolts that are not operated by the handle set. **FB = forever bronze so it will not change color over time like a true oil rubbed bronze would.

Read more less

Part Number: D304* W&F Trilennium 6 Inch CTC multipoint bore D304 is the new Replacement Handle Set -- Non stock item special order - Allow 1-2 weeks for your order to ship (unless otherwise noted on our website about extended lead times) - No order cancellations or returns    D304 is for doors with: 6 inch center to center 1 7/8" or  2 1/8" diameter bores and screw hole placement 5 3/16" Center To Center.  Requires: 1 11/16" or 2 1/8" crossbore Model: D304 Standard Set** Screw Hole Placement: 5 3/16" Center To Center  Size: for Door Thickness 1 3/4" or 2 1/4" Colors: Victorian Bronze , Satin Nickel, Bright Brass Style:  Active Standard 150 Degree- Has Thumb Turn, Keyed Cylinder and Lever is Operational*** For Single and French Active door panels. (Degree is how far the lever handle rotates for newer style multi point see pictures)  Active Modified 180 Degree*- Has Thumb Turn, Keyed Cylinder and Lever is Operational*** For Single and French Active door panels. (Degree is how far the lever handle rotates for older multi point and double bore systems see pictures)  Dummy - No Thumb Turn, No Key Cylinder and Fixed Lever****  For Inactive panels in French doors - that is fixed or has independent astragal installed  Tumbturn for 3020 - Has Thumb Turn, No Key Cylinder and Fixed Lever**** For Inactive panels in French doors that has 3020 lock installed only*** Handing: Universal  - Non handed works for both LH and RH swing doors Handle Sets have been known to have been used on Bayer, Pella, Peachtree and other door brands. Known W&F old handle set Pat No. 4,671,089 stamped on back of trim plate   Notes for other options for this style hardware on older doors: D304 is manufactured for the current multipoint system and will work for you right out of the box - order Active Standard 150 Degree (see pictures). If you have older style multipoint or backset lock and dead bolt with 6” center to center bore and screw hole placement is 5 3/16" Center To Center then Active Modified 180 Degree (see pictures) If your door has a 6 inch center to center 2 1/8" standard double bore with back set latch and dead bolt and screw holes are also 6" center to center you need to order part number 852).   If you are not sure what  type of system your door has, please send us pictures of your handle set with the door panel open so we can see the hardware that the handle set connects to inside the panel. Email pictures to: info@windowpartscenter.com footnotes: Non stock - Estimated 1-2 week for your order to ship - No order cancellations or returns  *Active Modified 180 Degree bushing or cartridge has no manufacturer warranty Warranty claims are handled on a case by case basis by the manufacturer. Pictures need to be emailed to info@windowpartscenter.com to submit a warranty claim for factory to review. This handle set also comes in other Models: See part numbers: D300, D301, D302, D304 ****Operational Lever: Can move up and down when door is unlocked Fixed Lever: Inactive, and is intended for push/pull function. Do NOT use a power driver tool to attach the handle set face plate retaining screws. Thread damage can result and is NOT considered a product defect.   Associated Parts Sold Separately:  S4112 - Peachtree Multipoint Mortise Lock Citadel IPD Citation For Trilennium Multi Point - Email us for quote. Info@WindowPartsCenter.com

Read more less

Part Number: D303* W&F Trilennium 6 Inch CTC multipoint bore D303 is the new Replacement Handle Set - Non stock item special order - Allow 1-2 weeks for your order to ship (unless otherwise noted on our website about extended lead times) - No order cancellations or returns  D303 is for doors with: 6 inch center to center 1 7/8" or  2 1/8" diameter bores and screw hole placement 5 3/16" Center To Center.  Requires: 1 11/16" or 2 1/8" crossbore Model: D303 Standard Set** Screw Hole Placement: 5 3/16" Center To Center  Size: for Door Thickness 1 3/4" or 2 1/4" Colors:  Victorian Bronze,  Satin Nickel, Black   Style:  Active Standard 150 Degree- Has Thumb Turn, Keyed Cylinder and Lever is Operational*** For Single and French Active door panels. (Degree is how far the lever handle rotates for newer style multi point see pictures)  Active Modified 180 Degree*- Has Thumb Turn, Keyed Cylinder and Lever is Operational*** For Single and French Active door panels. (Degree is how far the lever handle rotates for older multi point and double bore systems see pictures)  Dummy - No Thumb Turn, No Key Cylinder and Fixed Lever****  For Inactive panels in French doors - that is fixed or has independent astragal installed  Tumbturn for 3020 - Has Thumb Turn, No Key Cylinder and Fixed Lever**** For Inactive panels in French doors that has 3020 lock installed only*** Handing: Universal  - Non handed works for both LH and RH swing doors Handle Sets have been known to have been used on Bayer, Pella, Peachtree and other door brands. Known W&F old handle set Pat No. 4,671,089 stamped on back of trim plate   Notes for other options for this style hardware on older doors: D303 is manufactured for the current multipoint system and will work for you right out of the box - order Active Standard 150 Degree (see pictures). If you have older style multipoint or backset lock and dead bolt with 6” center to center bore and screw hole placement is 5 3/16" Center To Center then Active Modified 180 Degree (see pictures) If your door has a 6 inch center to center 2 1/8" standard double bore with back set latch and dead bolt and screw holes are also 6" center to center you need to order part number 852).   If you are not sure what  type of system your door has, please send us pictures of your handle set with the door panel open so we can see the hardware that the handle set connects to inside the panel. Email pictures to: info@windowpartscenter.com footnotes: Non stock - Estimated 1-2 week for your order to ship - No order cancellations or returns  *Active Modified 180 Degree bushing or cartridge has no manufacturer warranty Warranty claims are handled on a case by case basis by the manufacturer. Pictures need to be emailed to info@windowpartscenter.com to submit a warranty claim for factory to review. This handle set also comes in other Models: See part numbers: D300, D301, D302, D304 ****Operational Lever: Can move up and down when door is unlocked Fixed Lever: Inactive, and is intended for push/pull function. Do NOT use a power driver tool to attach the handle set face plate retaining screws. Thread damage can result and is NOT considered a product defect. Associated Parts Sold Separately:  S4112 - Peachtree Multipoint Mortise Lock Citadel IPD Citation For Trilennium Multi Point - Email us for quote. Info@WindowPartsCenter.com

Read more less

Part Number: 1172 - 1 1⁄2” x 11” Brass Plates, Concord Style - For Semi-Active Door EMTEK MULTI POINT LOCK TRIM DOOR CONFIGURATION 1 3 5/8" Center-to-Center (see diagram) Non-Keyed, Passage - For Semi-Active Door NOTE! - This is for Configuration style 1 doors only. Read all information below and review all diagram drawings and pictures before you place you order to confirm this trim handle set will work with your door. Made to order -  allow 1-3 week lead time - no returns or order cancelations - pricing includes factory shipping costs Reference:  Atrium®, G-U®, KML by Andersen®, Andersen®Marvin Integrity®, Paddock Lockmaster™, Superior® - see diagram to confirm this will work for your door. Each Multi Point Lock Trim now includes the Spring Assist functionwhich returns the lever to the neutral position and eliminatessagging handles. Handing Required (see diagram!!!) • Key codes may be specified. Fits standard door thickness of 13⁄4”. Specify if thicker in check out order comments.• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included. Finish:  Polished Brass - Lifetime (US3) French Antique (US7) Oil Rubbed Bronze (US10B) Satin Nickel (US15) Pewter (US15A) Flat Black (US19) Polished Chrome (US26) Unlacquered Brass (US3NL) - Email for quote Style Lever: See Lever Options Picture see and choose your lever style - if lever option is not available for you to choose please email us what you would like and if available we will email you  custom quote/invoice to order. Handle set trim could be longer then your original handle trim and a new screw hole may need to be drilled see diagram for Door Configuration  1 for screw hole placement.  California Residents Proposition 65 Warning Same Style Handle Set with Other Operation Options: Part Number 1171 - Keyed with American Cylinder (Can lock or unlock door from inside and outside - comes with keys)  Part Number 1172 - Non-Keyed Passage (NO LOCKING CAPABILITY)  Part Number 1173 - Non-Keyed American Style Thumbturn Inside (can ONLY be locked or unlocked from the inside NO keys) Part Number 1174 - Non-Keyed Fixed Handle Outside, Operating Handle Inside (NO LOCKING CAPABILITY) Part Number 1175 - Dummy Pair ( Fixed - NO locking or door operation capability)

Read more less

Part Number  823  GU Door Handle Extension 7/8" Includes Split Shaft Available Finish Colors:  Antique Brass Bright Brass Brushed Chrome Oil Rubbed Bronze  White  Lead Time can be up to 6 weeks Associated Parts Sold Separately: Part number  840 - GU Active Handle Set For GU Multi Point Hardware split shafts 829 Extensions 884

Read more less
