Sliding Patio Door Parts

Part Number: 529  Sold Individually  Measurement: 1 7/8" W x 1 1/8" H Known To Be Used On: Rite Screens, Hurd Current Screen Rollers 2006 to Present, Sierra Pacific WI Sliding patio Door screen. PVS4, SCPR47801 Associated Parts Sold Separately: 529SCREW - Screw Pack 1 Install Screw 1 Adjustment Screw

Read more less

Frost Barrier (for fiberglass sill seal) Used On Hurd Energy Saver Sliding & French Sliding Aluminum Clad Patio Doors. -Also called a Black Fiberglass Sill SealPlease note that on currently produced doors, this Frost Barrier is only placed in front of the operating panel (not in front of the fixed panel).For 5-0 Call out Wide - use 29" Frost BarrierFor 6-0 Call out Wide - use 35" Frost BarrierFor 8-0 Call out Wide - use 47" Frost BarrierFor 12-0 Call out Wide - Use 70" Fort BarrierFor 16-0 Call out wide - use 94.5" Frost Barrier - please e-mail info@windowpartscenter.com for custom invoice. A $150 adder has to be added due to UPS and fed ex 8’ or longer shipping adder. Color: Black OnlyKnown Part Number: 037330

Read more less

Part Number: 533 Manufacture: Amesbury Truth Known to have been used on:  For Hurd Sliding Patio Doors Manufactured Prior to 9/18/2006 and peachtree and any more that used Amesbury Truth Parts Old Style Stamped on part: 2153 Works as a replacement option for W&F keeper that has been discontinued

Read more less

Part Number: 534 Anti-theft bracket for  Sliding Patio Doors  Stainless Steel sold individually  Screws not included.  Factory recommends #8 x 1-1/2” PH FL SS Screws Known to been used on Hurd Sliding patio doors including FeelSafe and DP55 Upgrade Units, and Sierra Pacific "WI" Sliding patio doors

Read more less

Keeper Finder Marks Door Jamb for proper placement of Keeper.Works with Part # 533 Keeper

Read more less

Part Number 537 Charley Bar in Mill FinishFits door panels from 28” to 48” wideQuick and easy to install!

Read more less

Part Number: 540-A With Wings 41.10 Secondary Patio Door Limiter Foot Bolt Sliding Patio Doors (Foot Operated Lock) Spring loaded and foot-operated, this sturdy device easily engages to provide a more secure door and easily releases to provide a ready means of escape. In fact, this patio door limiter has been tested to withstand a forced entry attempt of 400 lbs. of forceMade in the U.S.A. Amesbury TruthStyle: 41.10 Color: White Or Bronze Keeper Option: 20824 (in stock) 30680 (in stock) 30672 (NOT in stock special order) Material: Acetal body, release lever and button. Cold-rolled steel bolt. RECOMMENDED SCREWS: (Screws Not Include)  SECONDARY PATIO DOOR LIMITER 41.10 WOOD: 4  #8 X 1.0 PHILLIPS, FLAT HEAD, SHEET METAL SCREWS PVC/METAL: 4-#8 PHILLIPS, FLAT HEAD SCREWS (LENGTHS AND THREAD TYPE TO BE DETERMINED BY PROFILE) For Keeper 20824 WOOD: 2  #8 X 1.0 PHILLIPS, FLAT HEAD, SHEET METAL SCREWS PVC/METAL: 2 - #8 PHILLIPS, FLAT HEAD SCREWS (LENGTH AND THREAD TYPE TO BE DETERMINED BY PROFILE) For Keeper 30680 WOOD: 2  #8 X 1.0 PHILLIPS, PAN HEAD, SHEET METAL SCREWS PVC/METAL: 2 - #8 PHILLIPS, PAN H EAD SCREWS (LENGTH AND THREAD TYPE TO BE DETERMINED BY PROFILE) For Keeper 30672 WOOD: 2 #8 X 1.0 PHILLIPS, FLAT HEAD, SHEET METAL SCREWS PVC/METAL: 2 - #8 PHILLIPS, FLAT HEAD SCREWS (LENGTH AND THREAD TYPE TO BE DETERMINED BY PROFILE)   Mounting: Mounts to bottom rail of sliding door and engages in sill, or into the face of the stationary door. See mounting positions “A” and “B”.Made in the U.S.A. Amesbury Truth (Stamped on Back 45010, and 30680)

Read more less

Part Number: 540-B; 41.13 Wingless  Secondary Patio Door Limiter Wingless Foot Bolt Sliding Patio Doors  Spring loaded and foot-operated, this sturdy device easily engages to provide a more secure door and easily releases to provide a ready means of escape. In fact, this patio door limiter has been tested to withstand a forced entry attempt of 400 lbs. of force. Material: Acetal body, release lever and button. Cold-rolled steel bolt Color: White or Bronze Keeper Option: 20824 (in stock) 30680 (in stock) 30672 (NOT in stock special order) Shim: Shim is ONLY needed for Hurd Brand all wood and wood clad Sliding Patio Doors Recommended Screws: (Screws Not Include)  For 41.13 Door Limiter WOOD: 4  #8 X 1.0 PHILLIPS, FLAT HEAD, SHEET METAL SCREWS PVC/METAL: 4-#8 PHILLIPS, FLAT HEAD SCREWS (LENGTHS AND THREAD TYPE TO BE DETERMINED BY PROFILE) For Keeper 20824 WOOD: 2  #8 X 1.0 PHILLIPS, FLAT HEAD, SHEET METAL SCREWS PVC/METAL: 2 - #8 PHILLIPS, FLAT HEAD SCREWS (LENGTH AND THREAD TYPE TO BE DETERMINED BY PROFILE) For Keeper 30680 WOOD: 2  #8 X 1.0 PHILLIPS, PAN HEAD, SHEET METAL SCREWS PVC/METAL: 2 - #8 PHILLIPS, PAN H EAD SCREWS (LENGTH AND THREAD TYPE TO BE DETERMINED BY PROFILE) For Keeper 30672 WOOD: 2 #8 X 1.0 PHILLIPS, FLAT HEAD, SHEET METAL SCREWS PVC/METAL: 2 - #8 PHILLIPS, FLAT HEAD SCREWS (LENGTH AND THREAD TYPE TO BE DETERMINED BY PROFILE) Mounting: Mounts to bottom rail of sliding door and engages in sill, or into the face of the stationary door. See mounting positions “A” and “B”.Made in the U.S.A. Amesbury Truth (Stamped on Back 45010, and 30680)

Read more less

Part Number: 541 Foot Bolt Sliding Patio Door - Secondary Lock Not a Stock Item Special Order (no returns or order cancelations on special order items once order has been placed).  Known to have been used on: Hurd, Sierra pacific

Read more less

Part Number: 542 Sliding Patio Door Rubber Bumper HurdColor: Black or Gray Only Random color shipped depending on availability Size: 3 inch or 4 inch Long - Once 3 inch is gone only 4 inch will be available and Customer can cut down to size if you need shorter Known to have been used on: Hurd, Sierra pacific

Read more less

Part Number 544 Amesbury Truth Signature Style Handle Set Two Point Locking For Sliding Patio Door Signature Style Handle Set 40.94 and 40.68- Truth (mortise lock box and keeper not included)  Model:  Standard 40.94 - contour shape which is both elegant in style and easy to grasp. Contemporary 40.68 - sleek modern design resulting in a contemporary look that is sure to compliment your door system. (If replacing 40.68 on existing door with 40.94 with dual mortise lock you will need to purchase Contemporary style keeper sold separately)  Style: Active with key - handle set comes with 2 keys and keyed cylinder, for exterior locking and unlocking capability. Dummy - for 4 wide sliding patio doors, secondary panel. no locking capability. Product Used On Hurd Energy Saver Sliding Patio Door. Direct replacement for Old style Energy Saver Handle Set #501Special Order Item - No Returns - lead time 2-3 weeks.NOTE: Part # 501 Handle set that is a Truth part and used on Hurd Energy Saver Sliding patio doors was used up until about February 2014. The Current handle set is called their Signature Style #544 and is slightly different from the #501. However they are interchangeable and # 544 will work on your door. Some staining or touch up may be required but screw holes are the same. Related Product Sold Separately: Mortise Box and Keeper for Old Style 501 Handle Set: Used with Part # 555 - Amesbury Truth 2 Point Recessed Mortise Lock & Keeper Kit Current Style Mortise box part number 558 Current Style Keeper Part Number C1059 40.94  Contemporary style keeper sold separately

Read more less

Click on picture to enlarge. Standard Binding Post Screw - Silver Mill Finish -$16.00 each. Fits in a 1/4" diameter whole. No other finishes available.UPGRADE Binding Post Screw - Chrome, Brass Dull Finish, Dark Bronze & 18-8 Stainless Steel $26 each. 1/4" Diameter. ***NOTE*** When using the Upgrade # 546U Binding post. The diameter is 1/4" so you will have to drill out the hole with a 5/16" drill bit for these binding post to fit.

Read more less
