Caradco Windows and Doors Replacement Parts and Hardware

Part Number 115 50 Series with traditional housing has been discontinued. Direct Replacement is the 60 Series with Ellipse Operator Short Arm 9 1/2" Measurement is taken from center of housing to center of nylon roller - see drawing to measure accurately on your operator.  Amesbury Truth Single Arm 50 Series  Operator Short Arm 9 1/2" Color in picture: Goldtone To determine what handing to order: Look at picture of part and match up your operator to our picture to determine if you need to order a Left or Right handing. Click on picture to enlarge to see handing, color and dimension of operators PLEASE NOTE: Operators Old Square Style has been discontinued by manufacturer - once our stock is depleted we will automatically send the New Style which is the direct replacement. New Style Operator face is rounded rather than square. Known Part Number: 45251, 7707    Replacement Parts for: Hurd, Marvin, Cascade, Caradco, BiltBest, Semco, Oldach Operators with Similar Housing But Different Arm Lengths:  Part Number S1082 - Truth/Wright Dyad Operator Part Number S1048 - Truth/Wright Dyad operator Part Number S1068 - Truth/Wright Dyad Operator Part Number 105 - Truth/Wright Straight Arm Part Number 115 - Truth/Wright Straight Arm Part Number 109 -Truth/Wright Straight Arm Part Number 112 - Truth/Wright Straight Arm Part Number S1037 -GU - Split Arm Dyad Operator Part Number S1038 GU - Split Arm Dyad Operator Kit Part Number 111 - Truth/Wright Split Arm Dyad Operator  Known Part Number: 15-31-32-051, 15-31-32-052

Read more less

Part Number: 135 Amesbury Truth T Crank Handle. Also called Wing handle or Butterfly Handle Crank Handle for Amesbury Truth 11/32 Spline OperatorsUsed primarily on: the Amesbury Truth DLX Maxim, 15 series, 11 series casement and awning window Operators.Colors In Stock: Goldtone, Bronze, White, Clay, Aluminum, Black, New Goldtone,   Special Order Colors: Chestnut Bronze, Brushed Copper Nickel, Off-White, Cocoa Brown, Bright White, (No returns 1 - 3 week lead time).  Special Order Colors: Email info@WindowPartsCenter.com for pricing quote. minimum order maybe required Oil Rubbed Bronze (this is a faux ORB),   Known Part Numbers: 136, Truth 40984, 021951, 37-125-2 Used on: Amsbruty Truth Operators, Norco, Hurd Casement and Awnings, Weather Shield, and more.  Replacement Parts for: Hurd, Semco, Marvin, Cascade, Caradco, BiltBest, Milgard, Sierra Pacific, Vetter and more. Replacement part for Hurd Casement and awing window operators Vintage Classic Style: 02/02/1998 - 9/17/2007 and many other window brands that use Truth Hardware

Read more less

Part Number 211 Truth 11 Series (11.12) Awning Short Arm Operator Single Pull - 16 1/4 Wide Colors In Stock: White, Bronze and New Goldtone  Special Order Color: Clay, Beige and Goldtone are special order item. 1-4 week lead time No Returns Known to be used on Hurd Brand Windows with glass widths: 19 & 23, this part has been used on many other window brands such as Weather Sheild, Caradco, Biltbest and more. Associated Parts Sold Separately:  Part Number 139 Crank Handle  Part Number 135 T Handle  Part Number 108 Knob Handle Part Number 218 Center Hook  Below video shows how to replace an awning operator. Steps are very similar when you are replacing part number 211.  Known Part Numbers: 211, U.S. PAT. 4505601, PAT. CAN. 1986, 4530, 30896, 11-12-32-001

Read more less

Part Number: 125  elbow lock Picture shows lock in the locked position.(down)Color: White, New Goldtone, Beige, Bronze, Chestnut Bronze, Clay and Coppertone Associated parts sold separately for Elbow Style Lock  Part Number 172 Elbow Style Lock Keeper Finder NOTE: 125 Elbow Style Lock is a replacement option for the Straight Arm and Curved Arm Lock (see pictures).  If you are using 125 as replacement option you may want to Add a Keeper Finder (P/N 172) to your window lock order. The Keeper Finder will assist you in installing your new locks. QTY One (1) Keeper Finder is all that is needed to install multiple locks.  Known Part Number: HCSE32, 091694, 091695, 016155, 061656, 018911, 018912 Known to use as repalcement lock for: Hurd, Biltbest, Caradco, Oldach, norco and more

Read more less

Part Number: 307 Clutch Pin Metal Clutch Pin for Compression Tilt Double Hung and Single Hung Jamb Liners.  Current style is the direct replacement for the old style. Screw hole and spoke are in the same location and size. See pictures that show old vs current style. Old style Size: 5/8" wide x 1 1/4" Tall - Spoke protrudes out 1/2" Material: Metal Used On: Biltbest, Hurd, WeatherSheild, Caradco and many other window brands.  Associated Parts Sold Separately: Part Number 308 Clutch Shoe

Read more less

DPart Number: 179 LOCK ONLY - Casement and Awning Sash Lock - Curved Handle for Casement and Awning Windows 179 Curve Lock is AS IS ITEM - (may have minor scuffs, etc.) - No returns all sales final. ONCE STOCK IS GONE the 125 Elbow Style it replacement style   Colors in Curved Style: Goldtone Handing: Right and Left.  Ad of 8/6/24 no left hand are available used p/n 125 for replacement  ***Please note that the curved handle lock has been discontinued by the manufacturer so we have limited stock. Once our stock is depleted we will ship out the new lock that is the direct replacement. You will need to retro fit the 125 Elbow Handle Lock (shown in picture) to your windows. Add a Keeper Finder (P/N 172) to your window lock order! The Keeper Finder will assist you in installing your new Elbow Style locks. QTY One (1) Keeper Finder is all that is needed to install multiple locks. Known Part Number: HCSE32 Known to have been used on: Hurd casement and awnings for units manufactured pre 1998. , Biltbest, Caradco, norco and more

Read more less

Part Number 215   Manual Window Wand For Clear Story Windows Special Order Item - NO RETURNS or Order Cancellations  - Normal Estimated Lead time 2 - 3 weeks, but can be longer. During Busy months with high order volumes lead time can be 8 - 12 weeks. Put those operable clearstory windows to energy-saving use with our clerestory extension crank. High mounted windows are excellent for capturing light while providing privacy, but they can also be “excellent” heat traps. It is now possible to vent the heat that rises to these areas as easily as opening any other window in the home.It’s inexpensive and can easily retrofit to existing or new window installations. By simple removal of the existing crank handle and replacement with an adapter (see Hex-Bolt part number 216 and 217 sold separately) the crank will open and close any operable clerestory window. It is not necessary to replace the current operator. Remember that you will only need one clerestory crank to operate all windows at the same height. Color: natural anodized aluminum  Size:  is the length of the Wand or Crank Length. (see Chart below) Styles available: Sill Mounted or Jamb Mounted (see picture or video)  You must buy corresponding adapter to use wand (sold separately) . See part # 216 or # 217  Don't know what size to order?  Distance from floor is the measurement from the floor to the window. Example if the distance from the floor to the window is 7' then its advised to get a 3' wand or Crank length. See Chart Below for factory recommendations on length. Chart: Distance From floor 7 foot = Factory Recommends 3 foot Crank LengthDistance From floor 8 foot = Factory Recommends 4 foot Crank LengthDistance From floor 9 foot = Factory Recommends 5 foot Crank LengthDistance From floor 10 foot = Factory Recommends 6 foot Crank LengthDistance From floor 11 foot = Factory Recommends 7 foot Crank LengthDistance From floor 12 foot = Factory Recommends 8 foot Crank LengthDistance From floor 13 foot = Factory Recommends 9 foot Crank Length (KD)*Distance From floor 14 foot = Factory Recommends 10 foot Crank Length (KD)*Distance From floor 16 foot = Factory Recommends 12 foot Crank Length (KD)* *KD = Knocked Down (wand shipped in 2 pieces and you have to screw them together). Parts sold separately: Part Number 216 - Crank Handle Adapter for ClereStory Windows "Female" Part Number 217 Clear Story Manual Window Wand Crank Adapter "Male"

Read more less

Part Number: 331 Special order items no returns, exchanges or refunds. Lead time is 4-8 weeks for your order to ship. Once you place your order you will not be able to cancel your order. Please See Chart To Order. (Second product picture and how to videos below) Compression Tilt Jamb Liners Comes with 1 Left and 1 Right Jamb Liner (see video below) For Tilt Windows with Either Single Strength or Insulated Glass 86E Series for 1 3/8" or 1 1/4" Sash Max Opening Height for 86E Series is 7-6 (90") Bottom of jamb cut to fits a 14 degree sill angle by manufacture.  Jamb Liner Width: 3 7/16" Wide Jamb Liner Length: See Chart Colors: White or Beige On Chart: Glass Size = Glass Height Videos on How to identify and order 331 part 1 and part 2: Installation Video: Known to have been used on: Hurd, Caradco, Biltbest, Kolby, Weather Sheild, Jeld-Wen and many more

Read more less

Part Number S4017 Pivot True V200 Two Way Adjustable Door Hinge - Ashland Colors In Stock: White and Oil Rubbed Bronze All other colors are not A STOCK ITEM ALLOW 3+ WEEKS LEAD TIME ONCE YOU PLACE YOUR ORDER - SPECIAL ORDER ITEM NO RETURNS HINGES ARE HANDED LEFT HAND AND RIGHT HAND - SEE PICTURE TO DETERMINE YOUR HANDING YOU NEED TO ORDER.  Discontinued Colors: Gold Powder Painted is discontinued. Once our stock is depleted they will no longer be available to order. If you can add to cart it is still available  Dimension Current Style:  4 inch wide x 4.25 inch tall Discounted Size: Old style that has been discontinued was 3.75 inch wide x 4.25 Tall. The current style we sell is what Marvin recommends as the replacement option which does require some retro fitting see drop down menu of picture's for Marvin instructions on how to retro fit as well as differences between the old hinge and new hinge and further questions on how to retro fit this hinge you would need to contact Marvin directly). Screws NOT Included Factory Recommends Using the Following Screws Per Hinge:  1 − #10x2 1/2″Phillips flathead wood screws (jamb) 5 − #10x3/4″Phillips flathead wood screws (jamb, stationary stile) 4 − #8x1 1/2″Phillips flathead wood screws (panel) To Adjust Door use: 5/32″ Allen wrench. Key Features:  All Hinges adjust both horizontally and vertically  A Solid brass extruded jamb wing allows for higher hinge carry capacity Hex head adjustment screws, not Phillips or slotted, to provide secure toll engagement and prevent stripping during adjustment  Stainless steel adjustment screws bromide superior corrosion resistance  An integrated hinge pin to provide security for out-swing and in swing doors, and will not lift up during normal door operation  Performance and Operation  Horizontal adjusts 1/16” further than most hinges on the market. Hinge system adjusts 1/4” vertically and horizontally  Extremely low adjustment force by vertically adjusting the door from below, not laterally like other hinge designs Provides and easy-to-see indicator line for accurate vertical adjustment A “maintenance and noise-free” operation, even after a million cycles, by incorporating an internal polymer bushing to eliminate any metal to metal contact  Exceeds BHMA-Grade 3 standards for wood, vinyl, aluminum and steel doors How to Adjust Hinge: It is best to lift the weight of the door panel off of the hinges, then adjust the hinge. This can be done by having a 2nd person lift up on the inside and outside door handle, when the door panel is open. First make horizontal adjustment. To adjust away from jamb turn horizontal adjustment screw counterclockwise using 5/32" Allen wench.  To Move panel toward jamb turn Allen screw clockwise. (Horizontal adjustment screw is located on the hinge leaf that has 2 screws on either side of it). Make any vertical adjustments only after you have completed any horizontal adjustments. To adjust the panels vertically, turn the vertical adjustment screw clockwise using a 5/32" Allen wench. To Lower the panel turn the Allen screw counter-clockwise. (Vertical adjustment screw is located on the bottom of the hinge in the hinge pin shaft) Known to have been used on: Marvin Ultimate In-swing Patio Doors (old style was used pre-2011 and current style was used starting July 30 2012 once they stock of old style ran out) Caradco Jeld-Wen Known Part Numbers: 02101216, 02101213, 02101218, 02101217, 02101210, 02101214, 02101212, 02101219, 02101211, 02101215, 02101220, 02101234, 02101236, 02101227, 02101224, 02101229, 02101228, 02101221, 02101225, 02101223, 02101230, 02101222, 02101226, 02101231, 02101235, 02101237

Read more less

Part # 208 Amesbury Truth 11 Series (11.16) Awning Operator Screws Not Included - Factory Recommended Screws: Wood : #10 X 1.0 PHILLIPS, FLAT HEAD, SHEET METAL SCREWS. PVC and Metal  #10 PHILLIPS, FLAT HEAD SCREWS (LENGTH AND THREAD TYPE TO BE DETERMINED BY PROFILE) Known to be used on Hurd brand windows from 1988-Feb 2, 1998 on. For Awning Windows 27,31,35,43 wide. Also have been used on multiple other window brands over the years.  Known Part Number: 208, U.S. PAT. 4505601, PAT. CAN. 1986, 45301, 11.16 OperatorKnown Brands: Hurd, Truth, Amesbury Truth, Biltbest, Cradco, Weather Sheild. Assocated Parts Sold Separately: Shoe Stud (part # 214)  Guide Bar 26 3/4” long Aluminum Finish   The below video shows how to replace an awning operator. Steps are very similar when replacing 208 awning operator.

Read more less

Part # 340 Current Style  Replacement Balance Spring End Clips For Double Hung and Single Hung Window Compression Tilt Jamb Liner Springs.Known To Have Been Used On: Hurd, Weather Sheild, BiltBest, Cradco, Oldac and more. To order Springs (Sold Separately)  See part Number 335

Read more less

Part Number: 117 Operator for Casement  Window Entrygard Truth 15 Series  Straight Arm 15.94 . Handing: Left Hand and Right Hand. See pictures that are labeled to determine your handing of your operator  Overall arm length 9 1/2 inch see Pictures  Known Part Numbers: 117 - U.S. Pat. 4,241,541 - CAN Pat. 350,432 - PAT 1982 Know Numbers Stamped on Housing and Gear: U.S. Pat. 4,241,541 - CAN Pat. 350,432 - PAT 1982, PAT.NO. 4,840,075, 45275, 31782L Handle and Cover Sold Separately See part # 139 for handle and #166 and #S1004 for cover. Known Replacement Parts for: Hurd, Marvin, Cascade, Caradco, BiltBest, Milgard, Sierra Pacific, Norco and more. Truth Factory Cut Sheet for 15 Series Streight Arm 15.49 Operator
